A961094NU Ideal Standard Thermostatic Cartridge Replacement for K6190AA Moments Shower Column
Send a photo of your item and we'll help confirm it.
Summary
Ideal Standard A961094NU Thermostatic Cartridge for K6190AA Moments Shower Column
Genuine Ideal Standard A961094NU thermostatic cartridge for the K6190AA Moments five-function shower column. This G3/4 cartridge incorporates a membrane and forms part of the shower's temperature-control assembly.
The cartridge regulates the mixed water temperature. It is a separate component from the A961087NU ceramic disc flow cartridge, so the two part numbers must not be treated as alternatives.
Technical Details
| Manufacturer's part code | A961094NU |
|---|---|
| Cartridge type | thermostatic cartridge with membrane |
| Nominal cartridge designation | G3/4 |
| Thread designation | TR-Gewinde |
| Material | brass |
| Length | 87.24mm |
| Diameter | 44.7mm |
| Gauze filters | 2 |
| O-rings | 3 |
| Grub-screw hole | none |
Confirmed Model Applications
- Ideal Standard K6190AA Moments five-function shower column
- Ideal Standard A950795AA Moments thermostat and diverter assembly
Before Ordering
Check the installed cartridge and control assembly before ordering. Compare the part code, cartridge shape, threads, filter positions and seal arrangement with your existing part. The G3/4 designation and external dimensions alone are not sufficient to identify the correct cartridge for another shower.
Installation
Isolate the water supplies before removing the cartridge and follow the shower manufacturer's servicing instructions. Apply suitable silicone grease to the cartridge O-rings during fitting.
Related Spares You May Need
- Ideal Standard A961087NU 3/4 Inch Ceramic Disc Flow Cartridge - a separate flow-control component listed for the K6190AA Moments shower column
- TACSIL 3g Premium Cartridge Silicone Grease - Part Number TAC86, for lubricating cartridge O-rings during fitting
