Hudson Reed PN398 Lever Handles
Send a photo of your item and we'll help confirm it.
Summary
Hudson Reed PN398 Lever Handles
This Hudson Reed PN398 is a pair of lever handles for selected Hudson Reed Tec lever tap assemblies. These replacement tap heads are used where the original control levers are damaged, marked, loose or missing.
The handles form the visible user control for opening and closing the tap valve or mixer assembly. They should be checked against the original handle shape, rod length, handle fixing arrangement and the valve or adapter beneath before ordering.
Technical Details
| Brand | Hudson Reed |
|---|---|
| Part Number | PN398 |
| Part type | lever handle pair / tap head pair |
| Height | 64mm |
| Length of rod | 61mm |
- Used with selected Hudson Reed Tec lever basin taps, bath taps and bath shower mixer assemblies
- A spline adapter or ceramic disc cartridge may also be required depending on the tap model and the condition of the existing valve parts
Before You Order
Check the original handle dimensions, lever rod length, spindle or adapter connection and the exact tap model code before fitting. Do not rely on handle height or rod length alone, as visually similar Hudson Reed and Ultra handles can use different adapters, cartridges or valve arrangements.
Confirmed Compatible Models
- TEL353 Hudson Reed Tec Lever Bath Tap Filler With Swivel Spout
- TEL313 Hudson Reed Tec Lever Wall Mounted Bath Mixer
- TEL315 Hudson Reed Tec Lever Mono Basin Mixer Tap inc Swivel Spout & Waste
- TEL317 Hudson Reed Tec Lever Wall Mounted Basin Mixer Tap
- TEL354 Hudson Reed Tec Lever Bath Shower Mixer With Swivel Spout Shower Kit & Wall Bracket
- PK317-PN398 Hudson Reed Minimalist Lever Wall Mounted Basin Mixer Tap Chrome
Related Spares You May Need
- Hudson Reed SPR06 Spline Adapter - Pair
- Ultra SPR02 1/2" Ceramic Disc Cartridges (20 Splines) - Hot and Cold
- Ultra SPR03 3/4" Ceramic Disc Cartridges (20 Splines) - Hot and Cold
- Ultra SPR05 3/4 Inch Flexi Connectors PR
- Ultra STECLTH Control Handle for A3004 Valves
- 56446SS Spline Adapter (7.6mm 24 Spline to 15.5mm 20 Spline)
- Hudson Reed A391 Thermostatic Cartridge (Ultra)
- Hudson Reed SB320 Tec Bath Diverter Handle and Diverter
If the original handle is difficult to remove, the handle sits loose after fitting, or the tap still drips once the handles are replaced, inspect the spline adapter and ceramic disc cartridges as well as the handle pair.
