Vado VEL-002A-C/P 29mm Flow Cartridge for VEL-149/RRK/DIV and VEL-149/RRK/SQ/DIV
SUMMARY
Vado VEL-002A-C/P is a 29mm shower valve flow cartridge used in selected Vado exposed thermostatic shower valves and showering columns with rigid riser and integrated diverter assemblies including VEL-149/RRK/DIV and VEL-149/RRK/SQ/DIV.
The flow cartridge controls water flow through the valve. A worn flow cartridge can cause poor shut-off, stiff or unreliable flow control, or water dripping from the shower head or outlet after the shower is turned off.
Technical Details
- - Part Number: VEL-002A-C/P
- - Part type: 29mm shower valve flow cartridge
- - Body diameter: 29mm
- - Square head diameter: 8.8mm
- - Distance between locating pins hole to hole: 18.2mm
- - Total height: 45.9mm excluding locating pins
Before Ordering
- - Match the existing cartridge to VEL-002A-C/P and check the valve model code before ordering.
- - Do not rely on body diameter alone because Vado flow cartridges can vary by valve model and internal layout.
- - Apply a suitable silicone grease to O-rings and seals during installation to help the cartridge seat correctly.
Confirmed Compatible Models
- - VADO VEL-149/RRKSQ/DIV-CP Velo square thermostatic Shower Valve with Diverter
- - VADO VEL-149RRK-RO-CP Adjustable Velo Round thermostatic Shower Valve with integrated Diverter
- - VADO VEL-149RRK-SQ-CP Adjustable Velo square thermostatic Shower Valve with integrated Diverter
- - VADO AQB-149RRK-SQ-CP Adjustable Velo Aquablade square thermostatic Shower Valve with Diverter
- - VADO HorI-149RRK-CP Horizon Showering column with thermostatic Shower Valve
- - VADO PHA-149RRK-CP Phase Showering column with thermostatic Shower Valve
- - VADO VEL-149/RRKRO/ATM-CP Atmosphere Round thermostatic Shower Valve
Related Spares You May Need
- - TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved - TAC86 - single-use silicone grease for cartridge O-rings and seals during installation.
- - VADO V-001B-PLA Replacement Shower Valve Thermostatic Cartridge - V-001B-PLA - listed on selected Vado Velo and column spare pages. Check the exact valve model before ordering.
- - Vado V-001C-PLA Thermostatic Cartridge Replacement for Celcius | Elements | Notion | Origins | Nuance | Soho | Tonic and Mix Shower Valves - V-001C-PLA - listed on the VEL-149/RRKSQ/DIV-CP spare page. Check the exact valve model before ordering.
- - Thermostatic Cartridge for Vado V-001A-PLA Wax | Suits WG-149 DGS-149 - V-001A-PLA - listed on selected Velo and Aquablade spare pages. Check the exact valve model before ordering.
- - VADO FR-SHOWER/9-C/P Flow Regulator - FR-SHOWER/9-C/P - shower outlet or handset inlet flow regulator rated at 9 litres per minute.
- - VADO FR-FLEXI/5-PLA Flow Regulator - FR-FLEXI/5-PLA - flexible-tail flow regulator rated at 5 litres per minute for selected Vado mixer applications.
- - 150mm Universal Shower Hose - NXT734 - NXT734 - hose for connecting a shower elbow or valve to a shower handset.
Troubleshooting
- - Symptom: water dripping from the shower head or outlet when turned off.
- - Likely Cause: worn flow cartridge, debris on the seals, or wear inside the valve body.
- - Solution: isolate water supplies, compare the removed cartridge with VEL-002A-C/P, clean the valve body and replace worn seals or cartridge parts as required.
If you are unsure which cartridge or related component your Vado shower valve needs, send Di Vapor a clear photo of the valve, handle assembly and removed cartridge for identification before ordering.
