Vado C-205-RTC Cold Ceramic Disc Cartridge

SUMMARY

Spare part: 1/2 Inch ceramic disc valve cold suits: KEN-109/CD, VIC-109/CD

The Vado C-205-RTC is a cold-side 1/2 inch ceramic disc valve for selected Vado 3 hole wall-mounted basin tap mixer assemblies. It controls the cold water on/off flow through the tap body and is identified for KEN-109/CD and VIC-109/CD applications.

A worn cold ceramic disc valve can cause poor shut-off, stiff handle movement or water continuing to drip from the spout when the tap is turned off. Check the existing cartridge code, thread, spline and seal colour before ordering, as hot and cold cartridges turn in opposite directions.

Technical Details

- - Total length including bottom seal: 76mm

- - Turn: Quarter turn

- - Diameter at widest point: 23.8mm

- - Top spline diameter: 7.8mm

- - Top spline teeth / notches: 20

- - Barrel diameter: 17.8mm

- - Lower thread: 1/2 inch

- - Bottom seal colour: Blue for cold side

- - Close direction: Clockwise close and anti-clockwise open

- - Upper thread closer to spline: 19.8mm

Confirmed Compatible Models

- - VADO KEN-109/CD-C/P Kensington 3 Hole Basin Tap Mixer Wall Mounted Spare Parts

- - VADO VIC-109/CD-C/P Victoriana 3 Hole Basin Tap Mixer Wall Mounted Spare Parts

Code Note

Older component pages and documentation may show the cold-side valve as VIC-VALVE/CD/CL-1/2. C-205-RTC is the verified cold-side cartridge code for this current listing.

Related Spares You May Need

- - Vado C-205-LTC Hot Ceramic Disc Cartridge

- - TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved

- - VADO FR-100/5-PLA Flow Regulator for VIC-109/CD-C/P tap assembly context

If the existing part has different dimensions, spline count, seal colour or operating direction, use the Di Vapor part identification service before ordering.
