Trevi E960566NU Inline Valve 19mm Assy (Ideal Standard)

Summary

Trevi E960566NU Moonshadow In-Line Shower Flow Cartridge 19mm - Ideal Standard

Trevi / Ideal Standard E960566NU ceramic-disc flow-control cartridge for Moonshadow in-line shower valves. Also known as the ILV cartridge or T-valve internals, this part fits inside the in-line control assembly rather than replacing the complete chrome valve.

The cartridge controls water flow and shut-off through the Moonshadow in-line valve. It is separate from the thermostatic cartridge that regulates shower temperature. A common symptom of a worn or poorly sealing flow cartridge is water continuing to drip from the shower head when the shower is turned off.

Technical Details

Confirmed Compatible Models

• Trevi Moonshadow L6811 ILV shower kit
• Trevi L6839AA Ascari built-in thermostatic shower valve with Moonshadow Dual ILV 3 Function kit - for the Moonshadow in-line flow controls
• Trevi Ascari L6839AA GEN1 shower assembly - for the Moonshadow in-line flow controls
• Trevi Moonshadow L7064AA ILV 3 Function kit - for internal repair of the E960738AA T-valve

E960738AA T-Valve Repair

E960566NU provides the internal cartridge used to repair the discontinued E960738AA complete chrome T-valve. It is not a complete-assembly replacement and should not be ordered where the external T-body or complete chrome valve assembly is required.

Before Ordering

Confirm that the fault is with the Moonshadow in-line flow control rather than the separate temperature-control valve. Check the shower kit or assembly code and compare the existing cartridge with the product photographs and measurements. A matching diameter alone does not establish fitment, and the Ascari name alone is not sufficient to identify the required cartridge.

Fitting and Fault Checking

Isolate the water supplies before dismantling the valve. Check the cartridge seating area and seals for debris or damage, and use suitable silicone grease on the seals during installation. After reassembly, restore the water supply and check operation, shut-off and connections for leaks. A temperature-only fault requires separate investigation rather than automatic replacement of this flow cartridge.

Related Spares You May Need

The silicone grease is an installation accessory. The other items below are separate spares for the associated L6839AA or L6839AA GEN1 shower assembly, not components supplied with E960566NU or parts required for every ILV repair. Check the individual component against the fault and existing assembly before ordering.

• TACSIL 3g cartridge silicone grease - TAC86
• Trevi A923348 volume-control handle carrier
• Trevi A953957NU11 temperature adjustment carrier
• Ideal Standard A963510NU sealing frame
• Ideal Standard E960086NU service valve and inline filter
• Trevi S960134NU thermostatic temperature-control cartridge
• Trevi E4745AA 135cm flexible shower hose with chrome Easyclean finish

For help choosing the right part, use the Di Vapor part identification service.
