Grohe 46191000 25mm Extension Kit

SUMMARY

GROHE 46191000 25mm Extension Kit for Concealed Single-Lever Bath and Shower Mixers

The GROHE 46191000 is a 25mm extension kit for concealed single-lever bath and shower mixer installations. It is used where the concealed mixer has been installed too deeply for the standard trim assembly to reach and seat correctly, providing an additional 25mm of installation depth.

The extension is associated with the GROHE universal 1/2 inch concealed single-lever mixer system and is used with bath and shower mixer trim sets fitted to the relevant concealed bodies. It is an installation-depth extension, not a flow cartridge.

Technical Details

- - Part code: 46191000

- - Part type: 25mm extension kit / extension set

- - Extension length: 25mm

- - Application: concealed single-lever bath and shower mixer installations

- - Concealed mixer system: universal concealed single-lever mixer, 1/2 inch

- - Manufacturer reference formats include 46191000, 46 191 and 46 191 000

- - Separate longer-depth 50mm extension set: 46343000

Confirmed Compatible Models

- - Grohe 19051000 Tenso Single-Lever Shower Mixer Trim

- - Grohe 19155000 Chiara Manual Shower Valve

- - Grohe 19285DC1 Essence Single-Lever Bath Mixer

- - Grohe 19285001 Essence Single-Lever Bath Mixer

- - Grohe 19286001 Essence Single-Lever Shower Mixer

- - Grohe 19296000 Lineare Single-Lever Shower Mixer

- - Grohe 19296001 Lineare Single-Lever Shower Mixer

- - Grohe 19315000 Allure Single-Lever Bath Mixer with Diverter

Before Ordering

Check the concealed mixer body and required additional installation depth before ordering. The 25mm extension dimension alone does not establish fitment with another concealed valve system. Relevant trim documentation references concealed bodies including 35 501 000, 33 961 000, 33 962 000, 33 963 000, 33 964 000, 33 965 000 and 33 966 000, depending on the trim set.

This extension should not be selected for a GROHE Rapido SmartBox installation simply because a 25mm extension is required, as Rapido SmartBox uses a separate extension-set family.

Related Spares You May Need

- - TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved - Part Number: TAC86
