Grohe 46058000 Automatic Diverter for Concetto, Europlus, Eurostyle and Quadra Valves
SUMMARY
GROHE 46058000 Automatic Bath Shower Diverter for Legacy Concealed Single-Lever Mixers
The GROHE 46058000 is an automatic bath/shower diverter assembly used in selected concealed single-lever bath and shower mixers. The diverter changes the water outlet between the bath outlet and shower outlet and is associated with a number of older GROHE mixer installations.
This is a generation-specific GROHE spare part rather than a diverter for every mixer carrying the same range name. GROHE identifies 46058000 for concealed 1/2 inch single-lever bath mixer applications up to 2010. Later versions within some GROHE ranges use a different diverter such as 46737000, so the exact mixer code and existing diverter should be checked before ordering.
Technical Details
- - Manufacturer part code: 46058000
- - Part type: automatic bath/shower diverter assembly
- - Application: selected concealed single-lever bath/shower mixers
- - Application period: up to 2010 for the GROHE concealed 1/2 inch single-lever bath mixer application
- - Total length excluding spring: 117.4mm
- - Thread diameter: 21.9mm
- - Widest diameter: 24.9mm
- - Finish: chrome
- - GROHE diverter knob reference: 46008000
- - GROHE round sealing washer reference: 0128300M
A worn or sticking diverter can result in poor changeover between the bath and shower outlets, water continuing from the unintended outlet or the diverter failing to remain in the selected position. Before ordering, compare the part code, dimensions and mixer generation with the existing installation.
Confirmed Compatible Models
- - GROHE Concetto 19346 Single-Lever Bath/Shower Mixer Trim
- - GROHE 19456 Quadra Bath/Shower Mixer Trim
- - GROHE 19536 Europlus Bath/Shower Mixer Trim
- - GROHE 19285 Essence Single-Lever Bath/Shower Mixer
- - GROHE 19297 Lineare Single-Lever Bath/Shower Mixer Trim
- - GROHE 19506 Eurostyle Bath Shower Mixer Trim
- - GROHE Eurosmart 19450 Single-Lever Bath/Shower Mixer Trim when used with the legacy 33305000 1997-2004 valve body
- - GROHE 33477
- - GROHE 19315 Allure Bath Shower Trimset
- - GROHE 19155000 Chiara Manual Shower Valve
- - GROHE 19506000 Eurostyle Bath Shower Mixer
- - GROHE 19534000 Euroeco 1995-2002 Bath Shower Mixer Valve
- - GROHE 32785000 Euroeco Special Final Assembly Set for Rapido E
- - GROHE 33305000 Eurosmart 1997-2004 Single-Lever Bath Shower Valve
- - GROHE 33305001 Eurosmart Single-Lever Bath/Shower Mixer
- - GROHE Chiara 19530000
Related Spares You May Need
- - GROHE 46191000 25mm Extension Kit
- - GROHE 46048000 GRO46048 46mm Ceramic Single-Lever Mixer Cartridge
