Dornbracht 9090032020090 Cartridge
Part number: D-9090032020090
Price: £168.00
Sale: £74.83
You save: £93.17 (55%)
Price includes UK VAT (Region: UK▼)
In stock
Is this the right part?
Send a photo of your item and we'll help confirm it.
Product description
Summary
Dornbracht 9090032020090 is a 1/2 inch clockwise open flow cartridge for selected Dornbracht wall valves and volume control assemblies. It is associated with Dornbracht code 0490032020090 and it is also known as 90 90 03 202 00 90.
The cartridge controls on and off water flow within the valve and helps restore correct shut-off when the original ceramic mechanism or internal seals have worn. A common symptom of failure is water continuing to drip from the shower head or spout after the valve is turned off.
Technical Details
| Brand | Dornbracht |
|---|---|
| Part number | 9090032020090 |
| Alternative code | 90 90 03 202 00 90 |
| Associated code | 0490032020090 |
| Part type | clockwise open flow cartridge for selected Dornbracht 1/2 inch wall valves |
| Fitting screw thread | 1/2 inch BSP / 20.7mm |
| Upper screw thread | 23.7mm |
| Total length | 138mm |
- Lower section uses black rubber instead of white
- Cartridge includes a friction bearing
- Supplied with 2 plastic spline adapters
- Brass adapter not included
Before You Order Check
- Check the exact part code on the old cartridge or valve documentation
- Check that the existing valve uses a clockwise open cartridge
- Check the thread sizes and overall length against the original part
- Check whether the installation needs the cartridge only or an alternative assembly version with cut-to-length shaft
Confirmed Compatible Models
- Dornbracht Symetrics Volume Control Counter-Clockwise Closing 1/2 Chrome 36 607 980-00 Spare Parts
- Dornbracht Symetrics Wall Valve Anti-Clockwise Closing 1/2 Brushed Platinum 36 607 980-06
- Dornbracht Symetrics Wall Valve Anti-Clockwise Closing 1/2 Platinum 36 607 980-08
- Dornbracht Symetrics Wall Valve Anti-Clockwise Closing 1/2 Brushed Durabrass 23kt Gold 36 607 980-28
- Dornbracht Symetrics Wall Valve Anti-Clockwise Closing 1/2 Brushed Chrome 36 607 980-93
- Dornbracht Symetrics Wall Valve Anti-Clockwise Closing 1/2 Brushed Dark Platinum 36 607 980-99 Spare Parts
- Dornbracht Symetrics Volume Control Counter-Clockwise Closing 1/2 Chrome 36 607 985-00 Spare Parts
- Dornbracht Symetrics Wall Valve Anti-Clockwise Closing 1/2 Brushed Platinum 36 607 985-06 Spare Parts
- Dornbracht Symetrics Wall Valve Anti-Clockwise Closing 1/2 Platinum 36 607 985-08
- Dornbracht Symetrics Wall Valve Anti-Clockwise Closing 1/2 Brushed Durabrass 23kt Gold 36 607 985-28
- Dornbracht Symetrics Wall Valve Anti-Clockwise Closing 1/2 Brushed Chrome 36 607 985-93
- Dornbracht Symetrics Wall Valve Anti-Clockwise Closing 1/2 Brushed Dark Platinum 36 607 985-99 Spare Parts
- xTool Thermostat Module IMO ST 060 113 2985 finish variants 00 06 08 28 93 99
- xTool Thermostat Module with 2 Valves IMO ST 060 111 2980 finish variants 00 06 08 28 93 99
- xTool Thermostat Module with 3 Valves IMO ST 060 111 3980 finish variants 00 06 08 28 93 99
