Dornbracht 9090031320090 1/2" Cartridge with Spline Adapter - Clockwise Open
SUMMARY
Dornbracht 9090031320090 is a 1/2 inch quarter turn ceramic flow cartridge supplied with a white spline adapter. It is used as the clockwise open hot side control cartridge in Dornbracht deck valve and three-hole basin mixer assemblies.
This cartridge opens clockwise and closes anti-clockwise. A worn flow cartridge can cause stiff handle movement, poor shut-off or water dripping from the spout when the tap is turned off. Replacing the cartridge restores correct open and close control and helps the valve seal properly again.
Technical Details
- - Quarter turn operation 1/4 turn.
- - Total length including white spline adapter: 65.6mm.
- - Total length excluding white spline adapter: 61mm.
- - Diameter at widest point: 23.8mm.
- - Top spline diameter including adapter: 12.9mm.
- - Top spline diameter excluding adapter: 7.8mm.
- - Top spline teeth / notches including adapter: 20.
- - Top spline teeth / notches excluding adapter: 20.
- - Barrel diameter: 16.8mm.
- - Lower thread: 1/2".
- - Upper thread closer to spline: 23.8mm.
- - Bottom seal colour: white.
- - Close direction: anti-clockwise close;
clockwise open.
- - Dornbracht Part Number: 90 90 03 132 00 90 (9090031320090)
- - Check the opening direction, spline arrangement and thread size before ordering. Do not identify fitment from dimensions alone.
Confirmed Compatible Models
Dornbracht Mem Deck Valve Anti-Clockwise Closing Hot - Brushed Platinum 20 004 783-06 Spare Parts
Dornbracht Mem Deck Valve Anti-Clockwise Closing Hot - Brushed Platinum 20 000 783-06 Spare Parts
Dornbracht Mem Deck Valve Anti-Clockwise Closing Hot - Platinum 20 000 783-08 Spare Parts
Dornbracht Mem Deck Valve Anti-Clockwise Closing Hot - Platinum 20 004 783-08 Spare Parts
Dornbracht Cl.1 Deck Valve Anti-Clockwise Closing Hot - Brushed Platinum 20 000 706-06 Spare Parts
Dornbracht Cl.1 Deck Valve Anti-Clockwise Closing Hot - Brushed Platinum 20 001 706-06 Spare Parts
Dornbracht Cl.1 Deck Valve Anti-Clockwise Closing Hot - Brushed Platinum 20 002 706-06 Spare Parts
Dornbracht Meta Three-Hole Basin Mixer with Pop-Up Waste - Matte Black 20 713 661-33 Spare Parts
Dornbracht Three Hole Tap Mixer with Drain 20713661 000010 Spare Parts
Related Spares You May Need
Dornbracht 9090031330090 1/2" Cartridge with Spline Adapter - Anti-Clockwise Open
TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved
Dornbracht Tap Fixing Set 0423100327890 Compatible Spare (04.23.10.0327890)
If you are unsure whether this is the correct cartridge for your tap send clear photos of the cartridge handle fixing and valve body with all visible numbers before ordering.
