Crosswater X1A018N-H 3/4 Inch On/Off Flow Cartridge - Hot Side
SUMMARY
Crosswater X1A018N-H 3/4 Inch Hot Side On/Off Flow Cartridge for Bath Taps and Mixers
Crosswater X1A018N-H is a 3/4 inch hot-side on/off flow cartridge used in selected Crosswater bath fillers and bath shower mixers. It controls the hot water flow through the tap or mixer and is operated by the hot-side handle.
The cartridge uses a quarter-turn ceramic disc mechanism. A worn flow cartridge can cause stiff handle movement, poor shut-off or water dripping from the bath spout or shower outlet when the tap or mixer is turned off.
Technical Details
- - Part Number: X1A018N-H
- - Part type: on/off flow cartridge
- - Nominal size: 3/4 inch
- - Side: hot
- - Operation: clockwise open and anti-clockwise close
- - Cartridge type: quarter-turn ceramic disc
Confirmed Compatible Models
- - DE322DC Crosswater Design Bath Filler
- - DE422DC Crosswater Design Bath Shower Mixer with Kit
- - KL322DC Crosswater Kai Lever Bath Filler Tap
- - KL422DC Crosswater Kai Bath Shower Mixer
- - TO322DC Crosswater Totti II Bath Filler
- - ML322DC Crosswater Mike Lever Bath Filler
- - PRO422DC Crosswater MPRO Bath Shower Mixer with Kit
- - DE1322DC Crosswater Design Bath Filler
- - DE322DC-AA002FC Crosswater Design Bath Shower Mixer
- - DE422DC-AA002FC Crosswater Design Bath Shower Mixer
The older Crosswater references DE322DC-AA002FC and DE422DC-AA002FC use the DE322DC and DE422DC mixers with the AA002FC floor-leg set.
Before Ordering
Match the X1A018N-H code and hot-side operating direction where possible before ordering. Some later Crosswater assemblies use the separate Crosswater X2A018N-H hot-side flow cartridge, but a formal supersession from X1A018N-H to X2A018N-H has not been confirmed.
Do not identify the cartridge from the 3/4 inch size alone because cartridges with similar dimensions can use different internal fitments, splines and operating directions. Isolate the water supplies before removing the existing cartridge and apply suitable silicone grease to the seals during installation.
Related Spares You May Need
- - Crosswater X1A018N-C 3/4 Inch Cold Side On/Off Flow Cartridge
- - Crosswater DE003 Lever for DE322DC and DE422DC
- - TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved
Not sure this is the right cartridge? Use the Di Vapor Part Identification Service and send us a photo of the part.
