Crosswater X2A018N-H 3/4 Inch On/Off Flow Cartridge - Clockwise OPEN
Send a photo of your item and we'll help confirm it.
Summary
The Crosswater X2A018N-H is a 3/4 Inch hot-side on/off ceramic disc flow cartridge for selected Crosswater bath taps, bath shower mixers and deck mounted panel valve assemblies. This cartridge is the clockwise open hot control used to regulate water flow through the tap or mixer body.
A worn flow cartridge can cause stiff operation, poor shut-off or water dripping from the spout or shower outlet when the tap or mixer is turned off. Match the code X2A018N-H and the hot-side clockwise open operation before ordering.
Technical Details
| Part Number | X2A018N-H |
|---|---|
| Part type | 3/4 Inch on/off flow cartridge |
| Cartridge type | quarter turn ceramic disc |
| Side | hot |
| Operation | clockwise open and anti clockwise close |
| Approximate overall length | 56 mm |
| Diameter at widest | 25mm |
| Spline | 20 teeth |
| Sealing points | 2 O rings |
Pre-order Checks
- Check the existing cartridge code where visible and compare the hot-side opening direction before ordering.
- Do not order by the 3/4 Inch size alone because flow cartridges with similar thread sizes can use different splines, lengths and opening directions.
- Isolate the water supply and relieve pressure before removing the old cartridge.
Confirmed Compatible Models
- BL440DCLV Crosswater Belgravia Lever 4-Hole Bath Kit
- BL440DC Crosswater Belgravia Crosshead Bath 4-Hole Set with Kit
- KL322DC Crosswater Kai Lever Bath Filler Tap
- KL422DC Crosswater Kai Bath Shower Mixer
- SE350DC Crosswater Svelte Deck Mounted Panel Valves
- BL422DC Crosswater Belgravia Crosshead Bath Shower Mixer with Kit
- BL422DC_LV Crosswater Belgravia Lever Bath Shower Mixer with Kit
- DE322DC Crosswater Design Bath Filler Deck Mounted
- DE422DC Crosswater Design Bath Shower Mixer with Kit Deck
- KO422DC Crosswater Komo Bath Shower Mixer
- BL422DC-FL Crosswater Belgravia Fleur-De-Lis Bath Shower Mixer
- PRO322DC Crosswater Mike Pro MPRO Bath Filler Tap
- IN422DC Crosswater Invito Bath Shower Mixer with Kit
