Crosswater CG1210FA2 On/​Off Flow Cartridge for EV1210EC Valves

SUMMARY

Crosswater CG1210FA2 On/Off Flow Cartridge for Kai EV1210EC and EV1211EC

Crosswater CG1210FA2 is an on/off ceramic disc flow cartridge for the Kai EV1210EC exposed thermostatic shower valve and EV1211EC thermostatic bath shower mixer.

It operates through the flow control handle to turn the water on and off and adjust the flow rate. Temperature is controlled by a separate thermostatic cartridge, and the EV1211EC uses a separate diverter to select the bath spout or shower outlet.

Technical Details

- - Brand: Crosswater

- - Part code: CG1210FA2

- - Function: On/off control and flow regulation

- - Mechanism: Ceramic disc

- - Fitting: Threaded screw-in body

- - Operating stem: Splined

- - Sealing features: Body O-ring and blue bottom seal

Confirmed Compatible Models

- - Crosswater Kai EV1210EC exposed thermostatic shower valve

- - Crosswater Kai EV1211EC thermostatic bath shower mixer

Check Before Ordering

These valve models use different cartridge versions. Check the original cartridge against the product photographs, including the body, thread, spindle and seals. Do not assume that CG1210FA2 and CG1210FA1 can be interchanged, or select the cartridge by installation year alone.

Symptoms and Servicing

Persistent dripping from the shower head or bath spout when the control is turned off can indicate that the flow cartridge is no longer sealing correctly. Dirt or debris between the ceramic discs can affect shut-off, so inspect the cartridge and valve for contamination.

Isolate the hot and cold water supplies before removing the cartridge. Rinse loose debris from the removed cartridge with clean running water, dry it and lightly lubricate the seals with suitable silicone grease before refitting. Keep the valve body free of debris when installing a new cartridge.

Related Spares You May Need

Match the handle and thermostatic cartridge versions to the existing components before ordering.

- - Crosswater TCG1210FA2 thermostatic cartridge

- - Crosswater LV1210FB1 temperature control lever handle

- - TACSIL 3g cartridge silicone grease (TAC86)

- - Crosswater LV1210FB2 chrome flow control handle

- - Crosswater LV1210FA2 lever handle

Use our part identification service if you need help choosing the right cartridge.
