Crosswater AQ3930 1/2 Inch Cold Ceramic Disc Headwork for Basin Taps - Compatible Spare
Crosswater AQ3930 is a 1/2 inch cold-side ceramic disc headwork for selected Crosswater basin taps. This compatible spare is supplied under Part Number CR-AQ3930.
The cold tap handle turns the splined spindle to operate the ceramic discs. Turning the handle clockwise closes the waterway and stops the cold flow.
Technical Details
- - Part reference: AQ3930
- - Part Number: CR-AQ3930
- - Part type: Ceramic disc tap headwork
- - Position: Cold side
- - Nominal size: 1/2 inch
- - Closing direction: Clockwise
- - Fitting: Threaded screw-in headwork
- - Handle connection: Splined spindle
Confirmed Compatible Models
- - Crosswater ML114DNC Mike Lever Mini Monobloc Basin Mixer
- - Crosswater Hey Joe HJ135DNC basin tap
Check Before Ordering
Check the original cartridge reference and confirm that you need the cold headwork before ordering. Match the body threads, spindle shape and handle connection against the photographs, as the tap range and 1/2 inch size alone are not enough to identify the correct part.
Dripping Tap and Fitting Advice
A persistent drip from the spout with the tap turned off may indicate a worn headwork, debris between the ceramic discs or a poor seal at the seating surface. Establish whether the hot or cold control is responsible before replacing a part.
Turn off both water supplies and release any remaining water before dismantling the tap. Remove debris from the seating surface, lightly lubricate the O-rings with suitable silicone grease and install the new headwork. Test the tap for leaks and make sure the cold control shuts off fully.
Related Spares You May Need
- - TACSIL 3g WRAS Approved Silicone Grease - TAC86 for lubricating cartridge O-rings and seals during fitting
- - Crosswater AQ2135 1/2 Inch Hot Ceramic Disc Headwork - CR-AQ2135 for the corresponding hot control on taps that use the AQ2135 reference
If you are unsure which part you need, use our part identification service.
