Cartridge for Roca 505122603 (A505122603)
Send a photo of your item and we'll help confirm it.
Summary
Cartridge for Roca 505122603 (A505122603)
Flow-control cartridge for Roca A505122603, also referenced as 505122603. This 1/2 inch left-hand quarter-turn headwork is used in the later production version of the Roca Loft Elite 5A4751C00 concealed wall-mounted basin mixer.
The headwork opens and closes a single waterway as the tap handle turns, controlling the water supply to the spout. It is a flow-control component rather than a thermostatic temperature-control cartridge.
Technical Details
| Part reference | A505122603 |
|---|---|
| Alternative manufacturer code format | 505122603 |
| Component type | Single-way tap flow-control headwork |
| Nominal size | 1/2 inch |
| Operating movement | Quarter turn, 90 degrees |
| Handedness | Left-hand |
| Application | Concealed wall-mounted basin mixer |
Confirmed Model Application
- Roca Loft Elite 5A4751C00 concealed wall-mounted basin mixer, versions produced after October 2006
Check the Production Version
The earlier version, produced before October 2006, used headwork reference 505121203. Do not assume that A505122603 can be fitted to an earlier tap body. Check the model, production version and existing cartridge before ordering.
Before Ordering
Compare the removed cartridge's spindle, spline profile, thread and sealing arrangement with the product photographs. Check the required closing direction separately; the left-hand designation alone should not be used to determine this. The nominal 1/2 inch size is not a complete set of cartridge dimensions and should not be used as the sole basis for selection.
Failure Symptoms and Fitting
A worn or damaged flow-control cartridge can allow water to continue dripping from the spout when the tap is turned off. Identify which headwork is causing the problem before ordering. Isolate the water supplies before removing the cartridge, and follow the tap's installation instructions when fitting and checking for leaks.
Not sure which cartridge you need? Use the Di Vapor part identification service for help.
