Bristan 00622131 3/4" Flow Control Cartridge Replacement for Prism Concealed Shower Valves
Send a photo of your item and we'll help confirm it.
Summary
Bristan 00622131 3/4" Flow Control Cartridge Replacement for Prism Concealed Shower Valves - Compatible Cartridge
This Bristan spare part is compatible with:
- Bristan Prism 3 Control Concealed Shower
Please note, the colour of the seal at the bottom can vary, however this doesn't affect the operation of the cartridge.
This replacement cartridge is compatible with Bristan 00622131. A 3/4 inch hot flow control cartridge used for the older Bristan Prism three-control concealed shower valve in the confirmed landscape configuration. It operates the hot-side flow control and is used to open and close the water flow through this control.
A worn flow cartridge can cause poor shut-off or water to continue dripping from the shower head or outlet when the shower is turned off. Replacing a failed cartridge can restore positive on/off flow control where the cartridge has been identified as the cause.
Technical Details
| Bristan reference | 00622131 |
|---|---|
| Compatible cartridge part number | BR-00622131 |
| Nominal size | 3/4 inch BSP |
| Total length including bottom seal | 52.9mm |
| Diameter at widest point | 28.8mm |
| Barrel diameter | 23.6mm |
| Top spline diameter | 7.65mm |
| Top spline | 20 teeth / notches |
| Lower thread diameter | 27.6mm |
| Upper thread diameter closer to spline | 24mm |
- Opens clockwise
- Closes anti-clockwise
- Bottom seal colour can vary without affecting operation
Before Ordering
Check the existing shower valve layout and cartridge against the measurements above before ordering. The 00622131 is confirmed for the older landscape Prism three-control valve and should not be assumed to fit the portrait version or the current PM2 SHC3STP C revision.
Confirmed Compatible Models
- Bristan PM SHC3STP Prism Concealed 3 Control Shower Valve Landscape - BR DV 231 (historic Bristan model code PM SHC3STPL C)
If you are unsure which cartridge you need use the Di Vapor part identification service.
Related Spares You May Need
- Bristan CAP 05262C Cap Chrome (MZ)
- Bristan 00515534 Shroud for Prism Valves (Chrome)
- Bristan 00622130 3/4 Inch Cold Flow Control Cartridge Replacement for Prism Concealed Shower Valves
- Bristan 00622415 Thermostatic Cartridge (Screw-in)
- Bristan APT 06753A Adaptor 3/4 to 1/2
- Bristan OR 08015 O Ring 17.17mm x 1.78mm (MZ)
- Bristan FX 06541 Fixing Kit (Screws + plugs)
- Bristan WSHR 08210 Washer - Fibre 1/2
- 150mm Universal Shower Hose - NXT734
- Bristan NUT 04335CSET-BL Compression Nut & Olive
