AVILION Flow Cartridge - Hot Side (AK92Q37)
SUMMARY
AVILION Flow Cartridge - Hot Side (AK92Q37)
The AVILION AK92Q37 is a hot-side quarter-turn flow cartridge for use where the installed shower valve or tap cartridge matches part code AK92Q37 and the measured cartridge specification.
This ceramic flow cartridge controls on and off water flow on the hot side. A worn flow cartridge can cause stiff operation, poor shut-off or water continuing to drip from the shower head or outlet after the control is turned off.
Technical Details
- - Part number: AK92Q37
- - Hot-side flow cartridge
- - 90 degree quarter-turn operation
- - Clockwise open and anti-clockwise close
- - 20 tooth spline
- - Overall cartridge length: 52mm
- - Thread: G1/2
- - Diagram markings include Ø18.3 Ø22.2 Ø23.8 Ø19 HEX16.8 Ø7.65 Ø6.65 and M4x1
Pre-Order Check
Check the part code orientation spline count thread and full cartridge dimensions against the cartridge being removed before ordering. Do not choose this cartridge from diameter or spline count alone.
Installation Note
Isolate the water supply before removing the old cartridge. Apply a suitable silicone grease to the o-ring and lower seal during installation to help the cartridge seat correctly and protect the seals.
Related Spares You May Need
- - TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved
- - AVILION Flow Cartridge - Cold Side (AK92Q38)
- - 482D566 Spline Adapter (7.6mm 20 Spline to 9.2mm 21 Spline)
