A954353NU11 Ideal Standard / Trevi 3/4 Inch On/Off Ceramic Disc Flow Cartridge for Taps and Shower Valves (Anti-Clockwise Close)
Send a photo of your item and we'll help confirm it.
Summary
S9614NU Ideal Standard / Trevi 3/4 Inch On/Off Ceramic Disc Flow Cartridge for Taps and Shower Valves (Anti-Clockwise Close)
Note: All brass version will be sent in place of the polymer version.
The Ideal Standard Trevi A954353NU11 is a 3/4 inch ceramic disc on/off flow cartridge used in selected Ideal Standard, Trevi, Sottini, Armitage Shanks and Sandringham bath taps, bath fillers, bath/shower mixers and valve assemblies. It closes anti-clockwise and is identified by Ideal Standard as a post-2001 3/4 inch SE ceramic disc cartridge.
The cartridge controls water flow by opening and closing the waterway through ceramic discs. A worn or damaged flow cartridge can cause poor shut-off or dripping from the bath spout or shower outlet after the control is turned off.
Technical Details
| Part Number | A954353NU11 |
|---|---|
| Manufacturer's alternative code format | A 954 353 NU11 |
| Part type | 3/4 inch SE ceramic disc on/off flow cartridge |
| Closing direction | anti-clockwise close |
| Manufacturer application era | post-2001 |
| Total height | 59mm |
| Number of splines | 18 |
| Spline diameter | 7.6mm |
| Fitting | 3/4" BSP |
| Current supply version | all-brass version supplied in place of the earlier polymer version |
| Cartridge pair | S960023NU consists of A954353NU11 and the clockwise-close A954352NU11 cartridge |
Before Ordering
Check the existing cartridge part number, 3/4" fitting, spline arrangement and anti-clockwise closing direction before ordering. Do not identify this cartridge from hot or cold position alone because its position can vary between tap and mixer designs.
If you are unsure this is the correct cartridge, use the Di Vapor Part Identification Service.
Confirmed Models and Applications Using A954353NU11
- Armitage Shanks E5068AA Sandringham S/L dual-control two-taphole bath/shower mixer
- Sottini E7654AA Bari dual-control two-taphole bath filler GEN1
- Ideal Standard E5413AA Ceramix dual-control two-taphole bath/shower mixer
- Ideal Standard E0156AA Academy dual-control two-taphole bath/shower mixer
- Ideal Standard E0146AA Academy dual-control one-taphole bath/shower mixer
- Ideal Standard E0635AA Waterways Q/T dual-control one-taphole bath filler GEN1
- Ideal Standard E0645AA Waterways Q/T dual-control one-taphole bath/shower mixer - Post-2001
- Armitage Shanks E5069AA Sandringham S/L dual-control two-taphole bath filler
- Ideal Standard E0070AA Silver dual-control three-taphole bath filler
- Armitage Shanks S7703AA Halo dual-control two-taphole bath filler
- Ideal Standard E0715AA Waterways Q/T dual-control two-taphole bath/shower mixer
- Ideal Standard E0126AA Academy dual-control one-taphole bath filler
- Ideal Standard B8255AA Ceraplan Disc dual-control two-taphole bath/shower mixer
- Ideal Standard E5412AA Ceramix dual-control two-taphole bath filler
- Ideal Standard B8254AA Ceraplan Disc dual-control two-taphole bath filler
- Ideal Standard B5106AA Cone pair bath taps
- Armitage Shanks S7593AA Accolade Q/T dual-control two-taphole bath/shower mixer
- Ideal Standard B8253AA Ceraplan Disc pair quarter-turn bath taps
- Armitage Shanks S7592AA Accolade Q/T dual-control two-taphole bath filler
- Ideal Standard E0136AA Academy dual-control two-taphole bath filler
- Ideal Standard B5110AA Cone dual-control two-taphole bath filler
- Armitage Shanks S7704AA Halo dual-control two-taphole bath/shower mixer
- Sottini E1955AA Alchemy dual-control two-taphole bath filler with lever handles
- Ideal Standard E0072AA Silver dual-control two-taphole bath filler
- Ideal Standard B7892AA Ceraplan SL dual-control two-taphole bath/shower mixer
- Armitage Shanks S7591AA Accolade Q/T dual-control one-taphole bath filler
- Ideal Standard E0705AA Waterways Q/T dual-control two-taphole bath filler
- Sottini E1954AA Alchemy dual-control two-taphole bath filler with crosshead handles
- Ideal Standard B5111AA Cone dual-control two-taphole bath/shower mixer
- Ideal Standard B7891AA Ceraplan SL dual-control two-taphole bath filler
- Ideal Standard B8246AA Ceraplan Disc dual-control one-taphole bath/shower mixer
- Ideal Standard B8244AA Ceraplan Disc dual-control one-taphole bath filler
- Ideal Standard E0715NP Waterways dual-control bath/shower mixer
- Sottini E5145AA GEN1 Reprise dual-control three-taphole bath filler
- Sottini E5165AA GEN1 Reprise dual-control four-taphole bath/shower kit
