Crosswater CR11715Q00 Diverter Cartridge for EV1251EC Valve

SUMMARY

Crosswater CR11715Q00 Diverter Cartridge for EV1251EC Thermostatic Bath Shower Mixer

NOTE: You will now receive the plastic version of the cartridge.

The Crosswater CR11715Q00 diverter cartridge is used in the Crosswater EV1251EC Touch thermostatic bath shower mixer valve. It controls the direction of mixed water between the bath spout and shower handset, allowing the user to select the required outlet.

This cartridge is a serviceable internal component of the exposed bath shower mixer. A worn, damaged or obstructed diverter can cause difficulty switching between outlets, water passing through the wrong outlet or dripping from the shower head or bath spout when the valve is turned off. Replacing a faulty diverter cartridge can restore normal outlet selection and water flow control.

Technical Details

- - Part number: CR11715Q00

- - Part type: Diverter cartridge

- - Application: Exposed thermostatic bath shower mixer valve

- - Function: Diverts mixed water between the bath spout and shower handset

- - Supplied version: Plastic cartridge

- - Previous construction: Earlier versions were manufactured in brass

- - Valve arrangement: Two water outlets with a stop position

Important Information Before Ordering

The CR11715Q00 material is now plastic instead of brass. Earlier versions of this cartridge were manufactured in brass, so the supplied part may look different from the original cartridge removed from your valve. Check the existing part number, cartridge design and shower valve model before ordering. Do not rely on the external appearance or dimensions alone to establish fitment.

Confirmed Compatible Models

- - Crosswater Touch EV1251EC Thermostatic Bath Shower Mixer

Installation and Maintenance

Before removing the diverter cartridge, isolate both the hot and cold water supplies. The Crosswater EV1251EC maintenance instructions describe removing the diverter handle covering plate, fixing screw, handle, stop ring and broached ring to access the internal cartridge assembly. Check for debris, scale and damage before fitting the replacement, and follow the manufacturer's instructions when reassembling the valve. Test the outlet selection and shut-off operation after installation.

Related Spares You May Need

- - Bossini Cristina CR11713Q00 Thermostatic Cartridge - controls the mixed water temperature in the EV1251EC valve

If you are unsure which cartridge you need, use the Di Vapor part identification service for help.
