Aqualisa 910537 Thermostatic Cartridge & Temperature control knob for Midas 110 BSM Valve (702247)
Send a photo of your item and we'll help confirm it.
Summary
No locking ring or stop ring included. The photo shows the stop ring, but the stop ring is no longer included.
Aqualisa 910537 thermostatic cartridge and temperature control knob for the Midas 110 BSM valve. This assembly controls the mixed outlet temperature in the shower or bath shower mixer valve and is used when the temperature control cartridge has failed or no longer regulates correctly.
This product includes the thermostatic cartridge and temperature control knob. The locking ring and stop ring are not included, so these should be retained from the existing valve if they are still serviceable.
Technical Details
| Part Number | 910537 |
|---|---|
| Product reference | 702247 |
| Part type | thermostatic temperature cartridge with control knob |
| Approximate cartridge diameter | 47.99mm |
| Approximate cartridge length | 128.99mm |
| Material | brass and plastic |
| O-rings | 3 |
| Grub screw hole | No |
| Long spline | No |
- The cartridge-only version is available separately if the existing control knob is being reused
Before You Order Check
- Check the valve is a Midas 110 model before ordering
- Check whether you need the cartridge with the control knob or the cartridge-only version
- Retain the existing locking ring and stop ring because they are not supplied with this product
- Confirm the hot supply is on the left and the cold supply is on the right when viewed from the front of the valve
Common Fault Symptoms
- Symptom: shower runs too hot or too cold. Likely Cause: thermostatic cartridge is not regulating correctly. Solution: replace the temperature cartridge and recommission the valve.
- Symptom: outlet temperature fluctuates during use. Likely Cause: worn cartridge or debris affecting cartridge movement or inlet filters. Solution: check the inlet filters and cartridge condition before fitting the replacement.
- Symptom: temperature knob turns but outlet temperature does not respond correctly. Likely Cause: failed cartridge or control engagement issue. Solution: inspect the control knob and cartridge interface and replace the cartridge assembly where required.
Confirmed Compatible Models
- Aqualisa MD110BSM Midas 110 Bath Shower Mixer Spare Parts
- Aqualisa MD110S Midas 110 Bar Mixer Shower Spare Parts
- Aqualisa MD110SC Midas 110 Mixer Shower Column Spare Parts
