Grohe 3282400L Eurosmart Cosmopolitan Single-Lever Basin Mixer (1/​2 Inch) S-Size Spare Parts

SUMMARY

GROHE 3282400L Eurosmart Cosmopolitan Single-Lever, Low-Pressure Basin Mixer Spare Parts

The GROHE 3282400L Eurosmart Cosmopolitan is a chrome single-lever monobloc basin mixer designed for low-pressure water systems. This S-size tap has a smooth body without a pop-up waste and is installed through a single tap hole.

The mixer uses a 35mm ceramic cartridge to control the water flow and blend the hot and cold supplies. Cartridge wear can cause stiff or irregular lever movement, poor temperature control or water dripping from the spout after the tap has been turned off.

Technical Details

- - Complete model code: 3282400L.

- - Product type: single-lever low-pressure basin mixer.

- - Finish: chrome.

- - Cartridge size: 35mm.

- - Approximate overall tap height: 186mm.

- - Approximate spout reach: 92mm.

- - Approximate outlet height above the mounting surface: 79mm.

- - Required mounting hole: 34mm diameter.

- - Maximum mounting-surface thickness: 30mm.

- - Approximate flexible hose length: 350mm.

- - Flexible hose connections: G3/8.

- - Cold-water connection: right-hand side.

- - Hot-water connection: left-hand side.

- - Smooth tap body without a pop-up waste assembly.

Before You Order Check

Confirm that the complete code marked on the tap or its documentation is 3282400L including the final letter L. Do not confuse this low-pressure model with 32824000. Check the existing outlet insert and cartridge components against the required spare before ordering because GROHE documentation shows alternative outlet configurations.

Isolate the hot and cold water supplies before dismantling the mixer. Flush the pipework before reassembly and ensure the cartridge seals, locating pins and body openings are correctly aligned when fitting the replacement cartridge.
