ZSPSBARCA10 Ultra Thermostatic Shower Cartridge for A3558 Shower Mixer Valves (Hudson Reed)

Summary

ZSPSBARCA10 Ultra Thermostatic Shower Cartridge for A3558 Shower Mixer Valves (Hudson Reed)

Question: How do I install the ZSPSBARCA10 thermostatic shower cartridge?

Answer: You can install the Ultra / Hudson Reed ZSPSBARCA10 cartridge by

1. Removing the cover cap on the temperature handle of the shower valve.

2. Use a Phillips screwdriver to remove the fixing screw. Slide the temperature handle out.

3. Remove the temperature stop.

4. Locate the grub screw of the push-fit cartridge. Loosen and remove the screw to pull the cartridge out.

5. Grease the 3 O-rings of the new Ultra ZSPSBARCA10 cartridge. Use silicone grease made especially for plumbing.

6. Insert the cartridge in the valve and reassemble the handle.

Question: My shower’s water temperature is going up and down. It became unstable recently and it has been getting worse. Will changing the temperature cartridge solve the problem?

Answer: Check to see if the valve is receiving a steady flow of hot and cold water from the boiler to the supply lines. If the water supplies are stable and the valve has no clogs, changing the thermostatic cartridge is a must.

This cartridge is the ZSPSBARCA10 which is for the Ultra Minimalist Thermostatic Bar Shower Valve A3558.

Question: How to remove a stuck temperature control handle?

Answer: Once all the fixing screws are out, a lot of force is needed to remove a stuck handle. The accumulation of debris can be due to poor water quality. We have a magnetic limescale inhibitor for 15 to 25mm pipework that can address such an issue.

Question: What should I do if the ZSPSBARCA10 cartridge does not fit in the valve?

Answer: Once this genuine Ultra cartridge is purchased and it is not the right part for your valve, you can return it to us provided the cartridge is not used and is still in perfect condition.

To make sure you get the right spare part, we have a Find a Part service (free of charge). Just go to that page and send us a clear photo of the cartridge or the shower valve. We will do our best to respond to you within 1 working hour. This is to ensure you will buy the correct part and get your shower fixed in no time.

Please click here for other Ultra spare parts. We have many in stock shower replacement parts that are ready to ship. (We ship worldwide.)
