Thermostatic Valve Cartridge for Hamat DDS-Allison 5-8843-ST Shower Mixer
Send a photo of your item and we'll help confirm it.
Summary
This is a thermostatic cartridge for the Hamat DDS-Allison, model ALLISON-5-8843-ST thermostatic shower mixing valve.
Hamat Group is an Israeli manufacturer of showers and have been sold throughout the world.
We deliver this cartridge worldwide.
The cartridge is a push fit installation (not a screw fit), with specifications as follows (which is information that can be found in the technical diagram in more detail):
| Number of teeth on top (smaller) spline | 24 teeth |
|---|---|
| Number of teeth on next (larger) spline | 60 teeth |
| Total length | 95.5mm |
| Width at widest point | 34mm |
| Width of widest o'ring | 30mm |
| Number of o'rings | 3 |
If your thermostatic handle on the shower mixer is becoming stiff to turn or if the shower isn't regulating the water temperature correctly then the thermostatic cartridge could be the problem and replacing it will fix the issue (if the cartridge is the problem).
