This is a sequential / concentric thermostatic shower cartridge which controls both water temperature and water flow. Please note that there are several cartridges in the market that look quite similar to this GF78897 cartridge however are different. One being the Triton 833101...
Thermostatic Shower Cartridge (GF78898) Cartridge Measurements: Total Length: 116.5mm Diameter at Widest Point: 33.8mm (at top o'ring) Top Spline Diameter: 7.6mm Top Spline Teeth / Notches: 20 Diameter at Top O'ring: 33.8mm Diameter at Middle O'ring: 28.9mm Diameter at ...
This is a reverse supplied thermostatic cartridge with the following technical measurements: Total Length (excluding wax thermostat): 96mm Diameter at Thread: 41.7mm Top Spline Diameter: 7.6mm Top Spline Teeth / Notches: 20 Stop Ring Spline Diameter: 20mm Diameter at Top ...
Genuine Vado CEL-RETROFIT/O thermostatic cartridge which replaces the CEL-001B-WAX cartridge. This Vado thermostatic cartridge is a screw fit installation and is used in the following Vado thermostatic showers: - Celcius Concealed CEL-148B - Elements concealed 3 handle the...
Genuine CEL-001C-WAX thermostatic cartridge which is used on the following Vado shower mixers: **Important** The brass version of this cartridge is now discontinued by Vado, therefore you will receive the Vado polymer replacement. O-ring 3 has been removed - Supplied cartridge...
VADO Celsius CEL-0023/B-C/P Temperature Shroud Used In All 148C Valves, All 128C ValvesThis shroud is used in the following Vado valves: - all 148C valves - all 128C valves - Notion NOT suitable for 2 or 3 way valves...
Mira 1736.703 Thermostatic Cartridge for Duo, Agile, Adept, Pronta Shower Valves. Please note that the spring is no longer included so you'll need to use the spring from the old cartridge on the new one. ...
Grohe 47217000 thermostatic cartridge (1/2" Inch) with non-rising spindle. Total Height: 81.6mm Diameter at Widest Point: 31.8mm This Grohe 47217000 cartridge is used in the following Grohe valves: - Grohe Amera 27013 Shower system - Grohe Aquatower 2000 27017 Aquato...
Inta BO910564 (PU900004XX) Thermostatic Cartridge for Puro Shower Mixer Valves Used in: Inta PU90010CP Inta Puro PU70014CP Inta Puro PU70024CP...
Altmans THEXCART Thermostatic Cartridge - Compatible Replacement Cartridge Measurements: Total Length: 84.5mm Diameter at Widest Point: 35mm Top Spline Diameter: 7.6mm Top Spline Teeth / Notches: 20 Barrel Diameter at middle O'ring: 31mm Lower Thread Diameter: 31.7mm Up...
Triton 83304970 HP Thermostatic Cartridge (with Seals) for HP8000 HP9000 and Combi HP Shower Valves...
Grohe 47885000 1/2 Inch Thermostatic Cartridge for Grohtherm 800 1000 Shower Bar Valves The Grohe 47885000 is used in the following Grohe valves: - Grohtherm 800 Thermostatic shower mixer 1/2″ - Grohtherm 1000 Thermostatic shower mixer 1/2″ To uninstall this cartr...
A963427NU Ideal Standard / Trevi Thermostatic Temperature Cartridge Adjustment Carrier and Handle Extension ...
Ideal Standard Easybox Slim Cartridge Temperature Handle Extender Carrier for A6379AA & A6378AA Valves (Extension). This part is used to extend the thermostatic cartridge. You can attach it onto the related parts below. Total Length: 67mm Diameter at bottom o-ring: 52mm ...
Inta i308088 Thermostatic Cartridge for Inta I-Plus Shower Valves. Cartridge Length: 115mm Diameter: 41.7mm Number of O'Rings: 3 Material: Brass and white plastic polymer Installation Type: Screw in Gauze Filters: 0 This cartridge has a Vernet element made in France. ...
Aqualisa 910385 DCV Thermostatic Cartridge for Dream Shower Valves This cartridge also has codes: 701215, 022817 You will receive the version of the cartridge which has a plastic thread as opposed to the old metal version....
Rada 1651.149 V12 Thermostatic Cartridge (Mira) The is used in the following valves: Rada V12 Exposed Valve Rada V12 B Concealed Shower Valve Cartridge Measurements: Total Length: 100mm (excluding green handle adapter) Diameter at Thread: 51.8mm Diameter at Top O'rin...
