Thermostatic Cartridge for Triton Alcor 83308730 | Lima | Caroli
Thermostatic Cartridge for Triton Alcor 83308730 | Lima | CaroliTriton Alcor 83308730 CartridgeLima and Caroli Thermostatic CartridgeTriton 83308730Triton 83308730 Thermostatic Cartridge83308730Triton Alcor 83308730

Thermostatic Cartridge for Triton 83308730 Alcor | Lima | Caroli

Part Number: 83308730

SALE: £98.64

You save: £50.25 (34%)
Price includes VAT
Quantity:
ADD TO BASKET
IN STOCK
Wrong Item? Click to see More
UK Lowest Price Guaranteed
Next Day Delivery Available
Product description

SUMMARY

This is a (screw in) thermostatic cartridge for Triton 83308730 which is used on the following models:

- Triton Alcor Dual Control Mixer Shower Valve
- Triton Caroli Dual Control Thermostatic Mixer Shower Valve
- Triton Lima Dual Control Shower Mixer Valve

The 83308730 cartridge has now been discontinued by Triton and cannot be manufactured any more.

Important: Please Read - The cartridge that you will receive is a new retrofit version of the 83308730 which looks slightly different to the photos. The 83308730 cartridge has now been discontinued by Triton and cannot be manufactured any more.

This is a screw in thermostatic cartridge.

Please compare the cartridge which you have to the images and technical diagrams here to make sure you order to correct cartridge first time.

Technical Information
- Number of Splines: On the small spline at the top which connects to the temperature control handle there is 24 teeth. The larger spline further down the cartridge there are 60 teeth.
- Total Length: 101mm (this is excluding the thermostat element which is protruding from the bottom)
- Width at Widest Point: 45mm
- Width of body at Bottom: 39.4mm
- Number of Filters: 2
- Material: Brass
- Colour: Brass and chrome mix

Common problems caused by faulty thermostatic cartridges:

Temperature Issues
- Constant hot or scolding water temperature even when temperature handle turned to the coldest setting.
- Constant cold water temperature even when temperature handle is turned to the hottest setting.
- Water temperature keeps fluctuating and won't give a constant flow of the desired water temperature.

Flow Issues
- The flow of water is poor compared to the pressure of the water entering the shower mixer valve.

Temperature Handle Issues
- Temperature handle may not move as smoothly as it did when first installed. This is likely to grow stiffer and stiffer over time, even to the point where it seizes up completely or becomes difficult to turn.
