Thermostatic Cartridge for Mira React 1744.108 (H04H) Shower Mixer Valve Bars
Part Number: REACT-1744-108
Price: £72.00
SALE: £54.83
You save: £17.17 (24%)
Price includes VAT
IN STOCK
Product description
SUMMARY
Thermostatic cartridge for Mira React 1744.108 Shower Mixer Valve Bars.This cartridge will fit the following models (yet not restricted to these):
- Mira React (H04H) From 01/12 - Current Product
- Mira React Shower Fittings (L87B)
From 07/00 - 06/04
Mira React Cartridge Technical Information
Cartridge Length: 103.65mm
Diameter: 34.5mm (at the widest point)
Diameter at Top O'Ring: 32.2mm
Diameter at Bottom O'Ring: 30mm
Diameter of top Spindle (which the temperature handle connects onto): 9.5mm
Number of Teeth on Handle Splindle: 24
Type: Push fit
Cartridge Material: Plastic nylon with brass spindle and Vernet France 0165 copper thermostat element
Number of O-rings: 3
Tiers of Splines: 1
Number of Gauze Filters: 2
Reasons to Replace Mira React Thermostatic Cartridge
- When you turn the temperature handle to make the water hotter, the water flow of the cold reduces hotter water doesn't come out.
- When you turn the temperature handle to make the water colder, the water flow of the hot reduces colder water doesn't come out.
- Poor water flow
- Stiff temperature handle (this usually means the cartridge has seized up)
- Lime scale will destroy the inner parts of the thermo cart after a period of time, which will stop the shower valve from working.
- Replacing the cartridge should restore the shower mixer bar back to its original operation.
If you need help, send us a photo of what you need here.
