Thermostatic Cartridge for Kartell KVIT & Plan (K-VIT) Shower Valve - 256253425
Send a photo of your item and we'll help confirm it.
Summary
Thermostatic Cartridge for Kartell KVIT (K-VIT / K.VIT) Shower Valve - 256253425. Used in the Kartell, Logik & Klassique ranges.
Cartridge Measurements:
| Total Length | 100mm |
|---|---|
| Diameter at Widest Point | 34.45mm |
| Top Spline Diameter | 10.6mm |
| Top Spline Teeth / Notches | 32 |
| Diameter at Top O'ring | 32.1mm |
| Diameter at Middle O'ring | 31.15mm |
| Diameter at Bottom O'ring | 29.25mm |
Product Overview
Thermostatic cartridge for Kartell KVIT and Plan (K-VIT) shower valves, part number 256253425, supplied as a compatible replacement thermostatic element. This cartridge controls the blending of hot and cold water inside the valve body to help maintain a stable, user-set temperature.
Common Signs of Failure
- - Water temperature fluctuates during use
- - Shower will not hold a consistent set temperature
- - Temperature control becomes stiff, erratic or difficult to adjust
Confirmed Compatible Models
- - Kartell KVIT and Plan (K-VIT) shower valves that use thermostatic cartridge 256253425
What Is Supplied
- - 1 x thermostatic cartridge for Kartell KVIT and Plan (K-VIT) shower valves (256253425)
Installation Notes
Isolate the hot and cold water supplies before servicing. Remove the valve trim and temperature control handle, undo the retaining ring, extract the existing thermostatic cartridge, then fit the replacement ensuring all seals are correctly seated. Reassemble and test for smooth temperature control and stable operation.
Related Spares You May Need
- - 256253425 Thermostatic Cartridge Removal Tool for Kartell KVIT and Plan (K-VIT) Shower Valve (256253425-33)
- - Retaining Ring Nut for 256253425 Thermostatic Cartridge (4C66)
- - Stop Ring for 256253425 Thermostatic Cartridge (6X4453)
- - Handle Adapter for 256253425 Thermostatic Cartridge (D3R74)
- - Contemporary Temperature Control Handle for 256253425 Thermostatic Cartridge (244968)
- - Round Chrome Temperature Control Handle for 256253425 Thermostatic Cartridge (326HEA4)
- - Traditional Temperature Control Handle for 256253425 Thermostatic Cartridge (6WC8693)
- - Square Chrome Temperature Control Handle for 256253425 Thermostatic Cartridge (H88722)
- - Square 42mm x 42mm Temperature Control Handle for 256253425 Thermostatic Cartridge (H88966)
- - Round Flow Control Handle for 256253425 Thermostatic Cartridge (QW4BF2P)
- - Round Chrome Flow Control Handle for 256253425 Thermostatic Cartridge (445449Y)
- - Lever Flow Control Handle for 256253425 Thermostatic Cartridge (P7QE)
- - Square Chrome Flow Control Handle for 256253425 Thermostatic Cartridge (U667H)
- - Square 42mm x 42mm Flow Control Handle (853AH5)
- - TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved
