Thermostatic Cartridge for Bonomi 122322/10
Send a photo of your item and we'll help confirm it.
Summary
Thermostatic Cartridge for Bonomi 122322/10 used in 122322, 122323, 122324 and 122328 Shower Mixer Valves
The Bonomi 122322/10 thermostatic cartridge is the temperature-control cartridge used in selected Bonomi concealed thermostatic shower mixer valves. It regulates the blended outlet temperature inside the valve body and is the part to check when the shower temperature is unstable, difficult to adjust or no longer responding correctly to the temperature handle.
This cartridge is listed for Bonomi 122322, 122323, 122324 and 122328 shower mixer valves. Check the part code on the existing cartridge, the valve model and the physical cartridge details before ordering, especially where the valve has separate flow controls or diverter controls fitted alongside the thermostatic cartridge.
Technical Details
| Part Number | 122322/10 |
|---|---|
| Part type | thermostatic shower valve cartridge |
| Function | temperature regulation |
| Cartridge diameter | 23mm |
| Spline diameter | 7.6mm |
| Splines | 20 |
| Length | 81.2mm |
| O-rings | 3 |
| Body material | plastic / nylon |
| Colour | black |
| Connection type | push-in |
Confirmed Used-In Models
- Bonomi Concealed Thermostatic Shower Mixer 122322 Spare Parts
- Bonomi Concealed Thermostatic Shower Mixer with 2/3 Ways Diverter 122323 Spare Parts
- Bonomi Concealed Thermostatic Shower Mixer with Diverter and Hand Shower 122324 Spare Parts
- Bonomi Concealed Thermostatic Shower Mixer 122328 Spare Parts
Related Spares You May Need
- TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved
- Bonomi 122322/189A Shower Valve Flow Cartridge - Anti-Clockwise Open
- Bonomi 122322/189B Shower Valve Flow Cartridge - Clockwise Open
A drip from the shower head or outlet when the shower is turned off is more commonly linked to a flow cartridge or shut-off cartridge rather than the thermostatic cartridge. For this valve group, check the 122322/189A and 122322/189B flow cartridges if the symptom is water passing when off.
If the valve model or cartridge identity is uncertain, compare the removed cartridge with the listed measurements and contact Di Vapor before ordering.
