Inta BO910564 (PU900004XX) Thermostatic Cartridge for Puro Shower Mixer Valves
SUMMARY
Inta BO910564 (PU900004XX) Thermostatic Cartridge for Puro Shower Mixer Valves
The Inta BO910564 (PU900004XX) is a thermostatic temperature and flow cartridge for selected Inta Puro shower mixer valves. It is used inside the shower valve body to control the mixed water temperature and flow through the valve.
This cartridge is intended for Puro shower mixer valve repairs where the original cartridge is worn, scaled, seized or no longer controlling temperature correctly. Before ordering, compare the code, cartridge shape, spline detail and valve model against the existing part.
Technical Details
- - Brand: Inta / Intatec
- - Part Number: BO910564
- - Additional cartridge code: PU900004XX
- - Part type: thermostatic temperature and flow cartridge
- - Application: Puro shower mixer valves
- - Matched checking details: 39mm cartridge diameter, 72.9mm overall length, 8mm spline diameter and 24 splines
- - The PU90014CP Puro Mini shower valve data identifies PU900004XX as the thermostatic temperature and flow cartridge.
Confirmed Used In Models
- - Inta PU90010CP Puro Mini Dual Control Shower Mixer
- - Inta PU90014CP Puro Thermostatic Mini Concentric Dual Control Shower
Repair Notes
A failing thermostatic cartridge can cause unstable mixed water temperature, poor temperature adjustment, restricted flow or a shower that does not respond correctly to the control. Flush the valve body and check the hot and cold supplies before fitting the new cartridge.
Apply a suitable silicone grease to the O-rings during installation to help the cartridge seat correctly and reduce the risk of seal damage. Do not force the cartridge into the valve body if it is not aligned correctly.
Related Spares You May Need
- - TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved
- - Inta PU20004CP 150mm Centre Connection Elbows
- - INTA 31448CP Puro Flexible Slide Rail Kit with Eco-Air Handset
