Hudson Reed A3051 Thermostatic Shower Cartridge (Ultra)

SUMMARY

Hudson Reed Ultra Thermostatic Cartridge for A3051 Concealed Sequential Shower Valve

This thermostatic shower cartridge is for the Hudson Reed / Ultra A3051 concealed sequential shower valve with a square faceplate.

The cartridge forms part of the valve's temperature control assembly, which mixes hot and cold water for showering. The A3051 uses a single sequential control: turning the handle opens the water flow and then adjusts the mixed-water temperature.

Technical Details

- - Part Number: HUD-A3051-CT

- - Part type: thermostatic shower cartridge

- - Valve type: concealed sequential thermostatic shower valve

- - Valve identification: A3051 with a square faceplate

Confirmed Models

- - Hudson Reed / Ultra A3051 concealed sequential thermostatic shower valve with square faceplate

Before Ordering

Compare your existing cartridge body, seal positions and spindle or adaptor connection with the product photographs. Check the connection to your original handle as well as the valve model. A matching range name or similar diameter alone is not enough to identify the correct cartridge.

Servicing Advice

Poor temperature control or water dripping from the shower head when the control is turned off should be investigated before replacing parts. Debris, worn seals, supply problems and incorrect calibration can cause symptoms that may otherwise be attributed to cartridge wear.

Isolate the hot and cold water supplies before removing the cartridge and follow the valve's servicing and calibration instructions. After fitting, check for leaks and confirm that the shower controls the water temperature correctly and shuts off fully.

Related Spares You May Need

- - TACSIL 3g WRAS Approved Silicone Grease for Tap & Shower Cartridges for lubricating cartridge O-rings and seals during fitting

If you are unsure which cartridge you need, use the Di Vapor part identification service for help.
