Hansgrohe 92999000 Thermostatic Cartridge for 13408-18 Valves

SUMMARY

Hansgrohe 92999000 Thermostatic Cartridge for 13408-18 Valves

The Hansgrohe 92999000 is an Equilibrium pressure balance cartridge used inside earlier versions of the Hansgrohe 13408181 concealed pressure balance valve. The cartridge balances the hot and cold inlet pressures to help reduce changes in mixed-water temperature when the supply pressure fluctuates.

Technical Details

- - Manufacturer code: 92999000

- - Cartridge type: Equilibrium pressure balance cartridge with non-return function

- - Total length: 85mm measured from the end of the chrome spindle to the opposite end

- - Height at seal: 46.5mm

- - Maximum diameter at seal: 45.6mm

- - Top spline diameter: 7.6mm

- - Top spline: 20 teeth or notches with a flattened section (this has been flattened off so not all splines are visible)

Confirmed Compatible Models

- - Hansgrohe Equilibrium Pressure Balance Valve 13408181 - earlier documented valve version using cartridge 92999000

Important

Later Hansgrohe documentation for valve 13408181 specifies cartridge 88640000. Remove the existing cartridge and confirm the code 92999000 or compare all key measurements before ordering. Do not select this cartridge from the valve number or diameter alone.

Installation Note

Isolate the hot and cold water supplies before dismantling the valve. Lightly lubricate the cartridge O-rings with suitable silicone grease and retain the original cartridge orientation. For a back-to-back installation, the cartridge can be rotated 180 degrees with the C marking positioned on the left.

Related Spares You May Need

- - TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved - single-use silicone grease for lubricating cartridge O-rings and seals during installation
