Hansgrohe 07001147 Pressure Balancing Thermostatic Cartridge Only For 13408-180 07001147
SUMMARY
Hansgrohe 07001147 Pressure Balancing Thermostatic Cartridge Only For 13408-180 07001147, 16408001, 33170078
Cartridge Measurements:
Type: Thermostatic, Pressure Balance, Non-Return Valve
Total Length (from end of chrome spindle to other end of cartridge): 85mm
Height: 46.5mm (at seal)
Diameter at Widest Point: 45.6mm (at seal)
Top Spline Diameter: 7.6mm
Top Spline Teeth / Notches: 20 (this has been flattened off so not all splines are visible)
Hansgrohe 07001147 is a pressure balancing thermostatic cartridge for the 13408-180 shower valve. This cartridge is also listed with reference codes 16408001 and 33170078.
The cartridge is used inside the valve to help control mixed water temperature and pressure balance. Replacing a worn or faulty cartridge can help restore normal shower operation where the original cartridge has become stiff, blocked, damaged or unable to regulate correctly.
Technical Details
- - Type: Thermostatic, Pressure Balance, Non-Return Valve
- - The top spline has been flattened off so not all splines are visible
Confirmed Model References
- - Hansgrohe 13408-180
Before Ordering
Check the existing cartridge code, valve reference and measurements before ordering. The 07001147 cartridge should not be confused with other Hansgrohe cartridges used in related 13408 valve documentation, including 92999000 and 88640000, as those are separate cartridge listings with different specifications.
Related Spares You May Need
- - TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved
