Grohe 46386000 56mm Ohm Cartridge for Grohmaster, Avensys and Tenso Valves
SUMMARY
GROHE 46386000 56mm SilkMove Ceramic Cartridge for Avensys Tenso Taron and Ectos Valves
This diverter flow cartridge will fit the following Grohe single lever products:
- - Grohe Tenso 33349 Single - lever bath/shower mixer 1/2"
- - Grohe Grohmaster 33 389 Avensys M Biv
Please note that this cartridge comes in different colours. It can be white or blue, however this doesn't affect the functionality of the cartridge in any way; it's simply aesthetics.
The GROHE 46386000 is a 56mm ceramic mixing cartridge used in selected GROHE single-lever shower and bath shower mixer valves. It controls both water flow and mixed-water temperature through movement of the operating lever. Older GROHE documentation may show the same cartridge code in the shortened format 46 386.
This GROHE spare part uses SilkMove ceramic cartridge technology and is fitted as the main mixing cartridge within the confirmed valves listed below. It should not be confused with a thermostatic cartridge or a separate bath shower diverter assembly.
Technical Details
- - Part code: 46386000
- - Historic code format: 46 386
- - Part type: ceramic mixing cartridge
- - Cartridge diameter: 56mm
- - Technology: GROHE SilkMove
- - Function: controls water flow and mixed-water temperature
- - Designed for selected single-lever shower and bath shower mixer valves
- - The Avensys installation documentation identifies the cartridge as non-reversible
- - On the documented Avensys installation, hot water connects on the left and cold water on the right when viewed from the operating position
Confirmed Compatible Models
- - GROHE 33 389 Grohmaster Avensys M BIV Shower
- - GROHE 33396IP0 Avensys Classic Single-Lever Shower Mixer
- - GROHE 33399IP0 Avensys Manual Shower
- - GROHE 33349000 Tenso Single-Lever Bath Shower Mixer 1/2 Inch
- - GROHE 33524IP0 Taron Single-Lever Bath Shower Mixer
- - GROHE 33397IP0 Ectos Single-Lever Bath Shower Mixer
Before Ordering
- - Check the model number of the existing GROHE valve and compare the removed cartridge before ordering, as other Avensys and GROHE shower valves use different cartridge designs
- - Do not identify this cartridge from its 56mm diameter alone
- - When fitting the cartridge, ensure its seals locate correctly within the valve body and tighten the retaining screws evenly
Related Spares You May Need
- - TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved - TAC86
