GF72618 Thermostatic Cartridge
Part number: GF72618
Price: £160.00
Sale: £97.88
You save: £62.12 (39%)
Price includes UK VAT (Region: UK▼)
In stock
Is this the right part?
Send a photo of your item and we'll help confirm it.
Product description
Summary
GF72618 Thermostatic Cartridge
Cartridge Measurements:
| Total Length | 115mm (including wax thermostat at bottom) |
|---|---|
| Total Length | 110mm (excluding wax thermostat at bottom) |
| Diameter at Widest Point | 49.54mm |
| Diameter at Stop Ring Splines | 22.81mm |
| Diameter at Upper Thread | 29.77mm |
| Top Spline Diameter | 9.6mm |
| Top Spline Teeth / Notches | 24 |
| Diameter at Top O'ring | 43.61mm |
| Diameter at Middle O'ring | 42.12mm |
| Diameter at Bottom O'ring | 41.34mm |
| Fitting Type | Screw Fix (44.85mm thread diameter) |
| Material | Brass |
