Crosswater PA06007 Thermosatic Cartridge Replacement

SUMMARY

Crosswater PA06007 Thermostatic Cartridge Replacement for Dial Shower and Bath Valves

The Crosswater PA06007 is a thermostatic cartridge for the Dial Central, Dial Kai Lever and Dial Pier shower and bath/shower valve models listed below. It regulates the mixed water temperature within the concealed valve assembly.

The valve uses a separate cartridge for flow control and shut-off. If water continues to drip from the shower head or bath outlet after switching off, check the on/off cartridge as part of the diagnosis before assuming that the temperature cartridge needs replacing.

Technical Details

- - Part number: PA06007

- - Part type: thermostatic temperature-control cartridge

- - Application: concealed Crosswater Dial shower and bath/shower valves

- - Temperature control operates separately from the flow and on/off control

Confirmed Compatible Models

Dial Central

- - DIAL-CENT-1 concealed thermostatic shower valve with one outlet

- - DIAL-CENT-2 concealed thermostatic shower valve with one outlet

- - DIAL-CENT-3 concealed thermostatic shower valve with two outlets

- - DIAL-CENT-4 concealed thermostatic shower valve with two outlets

- - DIAL-CENT-5 thermostatic bath/shower valve with two-way diverter

- - DIAL-CENT-6 concealed thermostatic shower valve with two outlets and handset

- - DIAL-CENT-7 concealed thermostatic shower valve with two outlets and three-mode handset

- - DIAL-CENT-8 shower valve with one outlet, fixed head and arm

- - DIAL-CENT-9 shower valve with one outlet, push-button slider kit and three-mode handset

- - DIAL-CENT-11 concealed thermostatic bath/shower valve with two outlets and handset

- - DIAL-CENT-12 concealed thermostatic bath/shower valve with two outlets and three-mode handset

- - DIAL-CENT-14 shower valve with two outlets, fixed head, arm and shower kit

- - DIAL-CENT-17 shower valve with two outlets, fixed head, arm and shower kit

- - DIAL-CENT-18 shower valve with one outlet, slide rail, handset and hose

- - DIAL-CENT-19 shower valve with two outlets, fixed head, arm and shower kit

Dial Kai Lever

- - DIAL-KAI-1 thermostatic shower valve with one outlet

- - DIAL-KAI-2 thermostatic shower valve with one outlet

- - DIAL-KAI-3 thermostatic shower valve with two-way diverter

- - DIAL-KAI-4 thermostatic shower valve with two-way diverter

- - DIAL-KAI-5 thermostatic bath valve with two-way diverter

- - DIAL-KAI-6 thermostatic shower valve with two-way diverter and handset

- - DIAL-KAI-7 thermostatic shower valve with two-way diverter and handset

- - DIAL-KAI-8 shower valve with one outlet, fixed head and arm

- - DIAL-KAI-9 shower valve with one outlet, slide rail and three-mode handset

- - DIAL-KAI-11 thermostatic bath valve with two-way diverter and handset

- - DIAL-KAI-12 thermostatic bath valve with two-way diverter and three-mode handset

- - DIAL-KAI-14 shower valve with two outlets, wall outlet, hose, handset, fixed head and arm

- - DIAL-KAI-16 shower valve with two outlets, slide rail, handset, fixed head and arm

- - DIAL-KAI-17 shower valve with two outlets, wall outlet, hose, three-mode handset, fixed head and arm

- - DIAL-KAI-18 shower valve with one outlet, slide rail and handset

- - DIAL-KAI-19 thermostatic shower valve with two-way diverter and kit

Dial Pier

- - DIAL-PIER-1 thermostatic shower valve with one outlet

- - DIAL-PIER-2 thermostatic shower valve with one outlet

- - DIAL-PIER-3 thermostatic shower valve with two-way diverter

- - DIAL-PIER-4 thermostatic shower valve with two-way diverter

- - DIAL-PIER-5 thermostatic bath valve with two-way diverter

- - DIAL-PIER-8 shower valve with one outlet, fixed head and arm

- - DIAL-PIER-9 shower valve with one outlet, slide rail, three-mode handset and hose

- - DIAL-PIER-14+ shower valve with two outlets, wall outlet, handset, hose, fixed head and arm

- - DIAL-PIER-17 shower valve with two outlets, three-mode handset, fixed head and arm

- - DIAL-PIER-18 shower valve with one outlet, slide rail, handset and hose

- - DIAL-PIER-19 shower valve with two outlets, wall outlet, handset, hose, fixed head and arm

Valve Body References

- - DL1000RC Dial thermostatic valve with dual controls in a portrait arrangement

- - DL1001RC Dial thermostatic valve with dual controls in a landscape arrangement

- - DL2000RC Dial thermostatic valve with three controls in a portrait arrangement

- - DL2001RC Dial thermostatic valve with three controls in a landscape arrangement

- - DL2001RC_BATH Dial thermostatic bath valve

Before Ordering

Check the valve model and existing cartridge before ordering. Reversed hot and cold supplies or an incorrect temperature setting can also cause temperature problems, so these should be checked before replacing the cartridge.

Installation Notes

Isolate both water supplies before servicing and follow the fitting instructions for your valve. Note the original cartridge orientation and apply a light coating of silicone grease to the seals when refitting.

On DL1000RC valves, the cartridge is retained by a clamp nut. Align the cartridge slot with the valve-body recess when refitting, with the shroud lug at the two o'clock position. The DL1000RC temperature spindle turns clockwise towards cold and anticlockwise towards hot. Check for leaks and check the temperature setting before use.

Related Spares You May Need

These parts are available separately. Select the spare for the valve or shower kit being repaired.

- - TACSIL 3g Silicone Grease - TAC86 - Lubricant for cartridge seals during servicing

- - Crosswater PM09001 Dial On/Off Cartridge - Separate flow-control and shut-off cartridge

- - Crosswater PA05199 Dial Valve Fixing Plate

- - Crosswater PA05204 Dial Valve Ring Nut

- - Crosswater PA05221 Check-Valve Locking Screw

- - Crosswater PA05323 Dial Collar

Outlet Icons

Match the icon to the outlet arrangement on your valve.

- - Crosswater PA01490ME1 Hand Shower Icon

- - Crosswater PA01490ME2 Shower Head Icon

- - Crosswater PA01490ME3 Bath Icon

SK630C Slider Kit Spares

The following slider-kit spares are for DIAL-CENT-9 and DIAL-PIER-9 installations using the SK630C rail.

- - Crosswater PA04008 SK630C Fixing Kit

- - Crosswater PM01052CH SK630C Slider Bracket

If you need help finding the right part, use our part identification service.
