Brass Push Fit Thermostatic Cartridge with Threaded Spline
Send a photo of your item and we'll help confirm it.
Summary
This is a brass push fit thermostatic cartridge with threaded spline. There is a long brass spline on this cartridge.
| Product | Thermostatic Cartridge |
|---|---|
| Installation | Push Fit |
| Material | Brass |
| Number of External O-Ring | 3 |
| Number of Gauzing | 2 |
| Total Length | 113.5mm |
| Handle splines | 10.5mm |
| Top o-ring (closest to handle) | 33mm |
| Middle o-ring | 32mm |
| bottom o-ring | 30.2mm |
This Thermostatic Cartridge (NH-24-CART) with threaded spline is eligible for next day delivery, provided it is ordered before 3:00 PM from Monday to Friday.
Not sure if this is the right thermostatic cartridge for your shower?
- Please send us a message or give us a call. We will gladly help you identify the correct spare part.
The Basics of a Thermostatic Cartridge
A thermostatic cartridge plays an integral function in how comfortable a shower can be. The device is responsible for mixing water coming from a boiler and a cold storage tank to an ideal temperature. A thermostatic cartridge can either be a push-fit or a screw-in. Its material range from brass to polymer to ceramic.
Thermostatic Wax Element
Temperature regulation is conducted by a small flat diaphragm capsule sitting quietly in the barrel of a thermostatic cartridge. The thermo-element contains wax susceptible to thermal expansion, breathing to moderate the influx of water in two extremes to produce a single median temperature determined by the shower user.
Stem and Splines
A stem is found on the top part of a cartridge barrel. It ascertains the total length of the cartridge and the stretch between the collar to the tap head.
The spline is located above the stem. Splines not only work as an anti-rotational tool, but it also allows ease when rotating a bath tap control handle. Cartridges can have a spline count beginning 18 to 32. Getting the right cartridge replacement spare part involves getting the spline teeth number right, or the cartridge will not fit the valve handle with exactness.
This thermostatic cartridge has threads on the spline.
