Vola VR3279-40 Chrome Shroud - Silk Steel Finish
SUMMARY
The Vola VR3279-40 is a replacement shroud for selected VOLA concealed shower and mixer trim assemblies. It is the VR3279 depth option in VOLA colour code 40 with a silk steel stainless steel finish and is used where the visible outer trim ring is worn, marked, missing or being matched to the existing VOLA finish.
This shroud sits over the valve body behind the operating handle to complete the exposed trim. Before ordering, match the existing part code, finish and wall-depth measurement rather than using diameter alone, as VOLA lists different shroud depths for different installation depths.
Technical Details
- - Part Number: VR3279-40
- - Finish: VOLA colour code 40 silk steel stainless steel finish
- - Total Height: 16mm
- - Diameter: 37.2mm
- - VOLA depth table for VR3279: 16mm shroud for A measurement 31 - 36mm
- - VOLA depth table also lists VR3279B as 12mm for A measurement 27 - 32mm and VR3279C as 8mm for A measurement 23 - 28mm
- - A 2mm key is shown in the VOLA fitting instruction for trim removal and refitting
- - Do not cut the membrane during installation
Confirmed VOLA Models and Systems
- - VOLA NR.41
- - VOLA VR512
- - VOLA 4002/L/V
- - VOLA 4003
Ordering Check
Check the installed shroud height, the finish code and the A measurement before ordering. VR3279-40 should not be selected solely because the outer diameter appears similar; the VOLA fitting table separates VR3279, VR3279B and VR3279C by wall-depth range.
Related Spares You May Need
- - Vola 3279 Chrome Shroud - VR3279
