A912747NU11 Ideal Standard / Trevi Multiport Cartridge Oring 50.39 x 3.53
Send a photo of your item and we'll help confirm it.
Summary
Ideal Standard A912747NU11 Multiport Bath Mixer Cartridge O-Ring 50.39 x 3.53mm
The Ideal Standard A912747NU11 is a sealing O-ring for the large A953190NU multiport single-lever cartridge used in selected bath fillers and bath/shower mixers. This part is also identified by the shorter reference A912747NU.
The O-ring provides a water seal at the cartridge assembly and is used when renewing a damaged or deteriorated seal during servicing. This is an individual sealing component, not the complete mixing cartridge or a full cartridge seal kit.
Technical Details
| Part Number | A912747NU11 |
|---|---|
| Part type | Multiport cartridge O-ring |
| O-ring dimensions | 50.39 x 3.53mm |
| Associated cartridge | A953190NU large multiport single-lever cartridge |
| Application | Selected single-lever bath fillers and bath/shower mixers |
- Complete cartridge not included
Confirmed Model Applications
This O'ring is used in the basing mixers and is used in the following tap models which used the large Multipoint A953190NU cartridge
- Ideal Standard Tratto A1358AA single-lever bath/shower mixer
- Ideal Standard Tratto A1359AA single-lever one-taphole bath filler
- Armitage Shanks Halo A3272AA single-lever one-taphole bath filler
- Ideal Standard Domi Solo A7690AA single-lever one-taphole bath filler
- Ideal Standard Domi Solo A7760AA single-lever one-taphole bath/shower mixer
- Ideal Standard Idyll E0285AA single-lever bath filler
- Ideal Standard Idyll E0305AA single-lever one-taphole bath/shower mixer
- Sottini Capello A3054AA single-lever bath filler
Before Ordering
Check the exact tap model, existing cartridge and both O-ring dimensions before ordering. Range names or a matching diameter alone are not sufficient to identify the correct seal. A962639NU is a separate, thinner O-ring and must not be confused with A912747NU11.
Identify the source of any leakage before replacing the seal. Do not assume that a new O-ring will resolve internal cartridge wear, a stiff operating lever or persistent dripping from the spout when the tap is turned off.
Fitting Notes
Isolate both the hot and cold water supplies before removing the cartridge. Inspect the seal groove and mating surfaces, remove deposits carefully and fit the new O-ring without twisting or pinching it. Apply a thin coating of suitable silicone grease during assembly, then reassemble the mixer and check for leaks after restoring the water supplies.
Related Spares You May Need
- TACSIL 3g Premium Cartridge Silicone Grease - for lubricating the O-ring during fitting
Not sure which part you need? Use the Di Vapor part identification service and send us a photo.
