Roca AG0159300R Cartridge for R33MFH Monoblock Mixer

Summary

Roca AG0159300R Cartridge for R33MFH Monoblock Mixer

Roca AG0159300R is an R33MFH Cold Start single-lever cartridge used in selected Roca monobloc basin and bidet mixer taps. It sits inside the tap body beneath the operating handle and controls water flow and the mixing of hot and cold water.

This cartridge is specifically identified by Roca as the Cold Start R33MFH version. Roca documentation distinguishes AG0159300R from other R33 cartridge variants, so the exact tap model and original cartridge reference should be checked before ordering.

Technical Details

• AG0200700R is a separate R33MFH cartridge kit supplied with nuts and keys and should not be treated as a confirmed superseding code for AG0159300R
• Do not identify this cartridge from diameter or visual similarity alone

Confirmed Compatible Models

Cartridge AG0159300R is used for the models below. Some Roca model references were produced with different cartridge constructions, so check the existing cartridge and internal arrangement before ordering.

• Roca Atlas A5A3190C00 Basin Mixer Cold Start
• Roca Atlas A5A3090C0R basin mixer with pop-up waste Cold Start
• Roca Atlas A5A3290C0R
• Roca Atlas A5A3990C0R smooth body medium-height basin mixer Cold Start
• Roca Atlas A5A3090C00
• Roca Atlas A5A3990C00
• Roca Atlas A5A3D90C00
• Roca Atlas A5A6190C00 bidet mixer with retractable chain
• Roca L20 A5A3B09C00 smooth body medium-neck basin mixer Cold Start XL handle - AG0159300R applies to the later construction; earlier versions use a different cartridge
• Roca L20 A5A3C09C00 extended basin mixer with pop-up waste Cold Start XL handle
• Roca L20 A5A6B09C00 bidet mixer with chain connector
• Roca L20 A5A3K09C00 - AG0159300R applies to the later construction; earlier versions use a different cartridge
• Roca L20 A5A3I09C00 basin mixer with pop-up waste Cold Start XL handle
• Roca Alfa A5A3L25C00
• Roca Alfa A5A3M25C00 single-lever basin mixer with chain connector Cold Start
• Roca Alfa A5A3P25C00
• Roca Alfa A5A6D25C00 single-lever bidet mixer with smooth body
• Roca Alfa A5A6E25C00 single-lever bidet mixer with chain connector
• Roca Alfa A5A6F25C00
• Roca Naia A5A3096C00
• Roca Naia A5A3A96CN0 single-lever basin mixer with smooth body Cold Start
• Roca Naia A5A3B96CN0 single-lever extended-height basin mixer with smooth body Cold Start
• Roca Monodin A5A3098C00
• Roca Malva A5A313BC00
• Roca A5A303BC00 basin mixer
• Roca A5A323BC00 basin mixer
• Roca A5A373BC00 basin mixer

Before Ordering

• Check the original Roca product code and cartridge reference before ordering because visually similar Roca mixers can use different internal cartridges
• For L20 A5A3B09C00 and A5A3K09C00 check the internal construction carefully because earlier versions use AG0141207R rather than AG0159300R
• A worn cartridge can cause stiff or poor lever movement incorrect mixing or water continuing to drip from the spout after the tap is turned off

Not sure this is the right cartridge? Use the Di Vapor Part Identification Service and we can help.
