Dornbracht 0424032230090 Pre-seal with built-in Isolators

SUMMARY

Dornbracht 0424032230090 is a pre-seal with built-in isolators for selected Dornbracht concealed single-lever mixer rough-in bodies. It is used as an integral stop component within the concealed mixer body and is fitted where the valve requires built-in supply isolation.

This part is also listed as an integral stop with integrated supply stops and is used in pairs on the confirmed Dornbracht concealed mixer bodies below. Check the exact mixer body code before ordering, especially where the mixer includes a safety unit, backflow preventor or series-specific concealed rough-in body.

Technical Details

- - Brand: Dornbracht

- - Part Number: 0424032230090

- - Part type: pre-seal with built-in isolators / integral stop with integrated supply stops

- - Size: Ø 15 x 33.5 mm

- - Quantity used per confirmed concealed mixer body: 2

- - Application: concealed single-lever mixer rough-in body with integrated supply stops

Confirmed Dornbracht Models

- - Dornbracht 3502097090 Concealed Single-Lever Mixer

- - Dornbracht 3502197090 Concealed Single-Lever Mixer With Backflow Preventor

- - Dornbracht 3507097090 Series Specific Concealed Single-Lever Mixer

- - Dornbracht 3507197090 Series Specific Concealed Single-Lever Mixer With Safety Unit

Pre-Order Checks

- - Confirm the rough-in body code on the installation paperwork or spare parts diagram before ordering.

- - Do not match this part by diameter alone, as Dornbracht uses different pre-seal and integral stop parts across different concealed mixer and thermostat bodies.

- - Two units may be required when servicing both hot and cold integrated supply stops in the concealed mixer body.

Installation Note

This is an internal service part for a concealed Dornbracht mixer body. Isolate the water supply before dismantling the valve and inspect the surrounding seals and stop components while the mixer body is open.
