Ultra SPR08 40mm Single Lever Manual Ceramic Cartridge for Basin Taps & Showers (Hudson Reed)

SUMMARY

Ultra SPR08 is a 40mm single lever manual ceramic cartridge used to restore water flow control and hot and cold mixing in selected Ultra and Hudson Reed basin taps, bath fillers, bath shower mixers, kitchen mixer taps and manual shower valves.

This cartridge is easy to replace. Access is gained by removing the handle grubscrew, taking off the lever, undoing the retaining ring or fixing screw and then replacing the old cartridge with the correct matching spare.

Technical Details

- - Nominal cartridge diameter: 40.08mm

- - Approx overall length: 63.72mm

- - Spindle length: 25mm

- - Locating pin centres: 25mm

- - Body colour: blue

- - Body material: plastic

- - 2 locating pins

- - 1 O-ring

- - No long spline

- - No grub screw hole in the cartridge body

Common Signs of Failure

- - Stiff or loose lever operation

- - Poor control of hot and cold water mix

- - Water dripping from the tap spout or shower outlet when turned off

What to Check Before Ordering

- - Match the part code SPR08 where shown on the original documentation or spare parts list

- - Check the cartridge diameter, overall length, spindle length and locating pin layout against the old cartridge

- - Check that your tap or shower valve is one of the confirmed models listed below

Confirmed Compatible Models

Hudson Reed Tec Single Lever Concealed & Exposed Manual Shower Valve Spare Parts A3200M

Ultra Ocean Concealed Exposed Manual Valve Chrome A3200 Spare Parts

Hudson Reed Ultra A3201 Nostalgic Manual Valve Concealed Shower Spare Parts

Ultra Eon Concealed Single Lever Shower Valve With Luxury Slider Rail Kit A3400 A3273A Spare Parts

Premier Nuie DTY304 Eon Single Lever Deck Mounted Bath Shower Mixer With Shower Kit and Wall Bracket Spare Parts

Hudson Reed Ultra PF303 Eon Single Lever Bath Filler Spare Parts

Hudson Reed Ultra PF304 Eon Single Lever Deck Bath Shower Mixer Spare Parts

Hudson Reed Ultra PF305 Eon Single Lever Mono Basin Mixer Spare Parts

Hudson Reed Nuie PF306 Eon Single Lever Mono Bidet Mixer Tap Spare Parts

Hudson Reed Ultra KA306 Eon Mono Sink Mixer Tap Spare Parts

Hudson Reed Ultra KA307 Eon Mono Sink Mixer with Pull Out Rinser Tap Spare Parts

Hudson Reed Ultra PC303 Hola Single Lever Deck Bath Filler Spare Parts

Hudson Reed Ultra PC304 Hola Single Lever Wall Bath Filler Spare Parts

Hudson Reed Ultra PC305 Hola Single Lever Mono Basin Mixer Tap Spare Parts

Hudson Reed Ultra ML305 Liscia Single Lever Mono Basin Mixer Tap Spare Parts

Ultra Modern Surf Single Lever Mono Basin Mixer Chrome PP385 Spare Parts

Ultra Modern Flame Deck Mounted Bath Shower Mixer PV304 Spare Parts

Ultra Modern Flame High Rise Mixer Chrome PV370 Spare Parts

Hudson Reed Ultra TAS303 Aspire Wall Mounted Bath Filler Tap Spare Parts

Hudson Reed Ultra TAS304 Aspire Wall Mounted Bath Shower Mixer Spare Parts

Hudson Reed Ultra TAS305 Aspire Mono Basin Mixer Tap Spare Parts

Related Spares You May Need

150mm Universal Shower Hose - NXT734
