INTA NC25XXX Thermostatic Self Closing Cartridge for NC250CP
SUMMARY
This Inta NC25XXX thermostatic self closing cartridge is the replacement service part used in the NC250CP thermostatic non concussive basin mounted mixer tap with adjustable temperature control.
In the NC250CP assembly this cartridge manages the thermostatic mixing and timed self-closing operation, and the servicing instructions state that it should be removed and replaced as a complete self-contained unit.
Technical Details
- - Part Number: NC25XXX
- - Part type: thermostatic non-concussive self closing cartridge
- - Application: Inta NC250CP timed flow thermostatic basin mixer tap
- - Timed flow in the NC250CP tap: 15 seconds +/- 5 seconds at 1 bar
- - Factory set outlet temperature for the NC250CP tap: 41C
- - Operating pressure for the NC250CP tap: 1.0 to 5.0 bar
- - Maximum inlet temperature for the NC250CP tap: 65C
- - The cartridge is specified within a tap system that uses hot inlet on the left and cold inlet on the right when viewed from the front
Symptoms of Wear
- - Control knob cannot be depressed fully
- - Control knob does not return to its start position within about 15 seconds
- - Water temperature is difficult to adjust
- - Water flow is not steady
Before You Order
- - Check the tap model is NC250CP
- - Check the cartridge code is NC25XXX
- - Compare your existing part against the NC250CP spares drawing before ordering
Confirmed Model Application
