Ideal Standard B961902NU Multiport Small Cartridge

SUMMARY

Ideal Standard B961902NU Small Multiport Single Lever Cartridge for Taps and Shower Valves

The Ideal Standard B961902NU is a small multiport single-lever ceramic cartridge used to control water flow and blend hot and cold water in selected Ideal Standard, Sottini, Trevi and Armitage Shanks taps and manual shower valves.

B961902NU is supplied as the current replacement for the former A951970NU11 small multiport cartridge. The replacement has a different body appearance and dimensions from the discontinued cartridge, so identify the part by its code, port arrangement, locating pin, seals and handle connection rather than diameter alone.

Technical Details

- - Part number: B961902NU

- - Part type: small multiport single-lever ceramic cartridge

- - Function: on/off flow control and hot/cold water mixing

- - Material: plastic cartridge body with ceramic operating components

- - Colour: white

- - Body diameter: approximately 37.3mm

- - Overall length: approximately 62.1mm

- - Sealing arrangement: two O-rings

- - Locating arrangement: one locating pin

- - Handle connection features: no grub-screw hole and no long spline

Common Failure Symptoms

A worn or damaged B961902NU cartridge can cause water to continue dripping from the shower head or tap spout when the control is turned off. Other symptoms can include a stiff lever, poor flow control, difficulty shutting off the water fully or difficulty obtaining the intended mixed-water temperature.

Before Ordering Notes

Compare the existing cartridge code, overall body shape, port arrangement, locating pin position, O-ring positions and handle connection before ordering. The model fitment below applies to versions originally fitted with A951970NU11 because some mixer model codes were produced with different cartridges during later production periods.

Confirmed Compatible Models

- - Ideal Standard E0265AA Idyll single-lever one-taphole bidet mixer with pop-up waste

- - Sottini A4515AA Defacto single-lever one-taphole bidet mixer with pop-up waste

- - Ideal Standard E7836AA Affinity single-lever one-taphole sink mixer

- - Sottini A6473AA Mazaro built-in wall-mounted basin mixer

- - Ideal Standard A6337AA Tonic II exposed single-lever shower mixer

- - Sottini A4514AA Defacto single-lever vessel basin mixer without waste

- - Ideal Standard A7600AA Domi Solo single-lever basin mixer

- - Sottini A5537AA Defacto single-lever basin mixer without waste

- - Ideal Standard A1165AA Class single-lever basin mixer with pop-up waste

- - Trevi A4000AA Blend built-in single-lever manual shower valve

- - Trevi A3086AA Blend exposed high-flow single-lever manual shower valve

- - Ideal Standard E0083AA Silver single-lever one-taphole sink mixer

- - Ideal Standard E0245AA Idyll single-lever basin mixer with pop-up waste

- - Sottini A4513AA Defacto single-lever standard basin mixer with pop-up waste

- - Ideal Standard A1395AA Tratto single-lever basin mixer with pop-up waste

- - Armitage Shanks S7833AA Sandringham built-in manual shower valve

- - Ideal Standard A1397AA Tratto single-lever bidet mixer with pop-up waste

Related Spares You May Need

- - Armitage Shanks E960008NU Capello Drive Insert

- - Ideal Standard A963372NU Adapter for Capello Handle Fixation

- - Ideal Standard A961637NU Cartridge Retaining Nut for relevant A4000AA and S7833AA installations

- - Trevi A960571NU Plastic Manifold for Old Multiport Cartridge for relevant A4000AA and S7833AA installations

- - Ideal Standard A960034NU Handle Adaptor

- - Ideal Standard A962715NU Cartridge Sealing O-Ring 35mm x 3mm for relevant mixer models

- - Ideal Standard A963022NU Cartridge Retaining Nut M43 x 1.5 for the A7600AA Domi Solo installation

- - Armitage Shanks A962981NU Washers and Nut for Multiport Handle for relevant Tratto and Blend mixer assemblies

Check the spare-parts diagram for the exact tap or shower valve before ordering retaining nuts, manifolds, adaptors or seals because these supporting parts are model-specific and are not required in every installation.
