Vado C-303-RTC Cold Ceramic Disc Cartridge
Send a photo of your item and we'll help confirm it.
Summary
spare part: 3/4? ceramic disc valve cold suits: ELW/ELA-125-3/4, ELW/ELA-139-3/4, ELW/ELA-135-3/4, ELW/ELA-135/NS-3/4, ELW/ELA-126S, ELW/ELA-126L, ELW/ELA-142-3/4, ELW/ELA-143-3/4, NUA-135-3/4, NUA-139, NUA-135/NS-3/4, NUA-126S, NUA-126L, NUA-125-3/4, NUA-143-3/4, NUA-142-3/4, SEN-135-3/4, SEN-135/NS-3/4, SEN-142/PR-3/4, SEN-143-3/4, TON-126S, TON-126L, TON-135, TON-139, TON-131S, TON-125-3/4, TON-142-3/4, TON-143-3/4, VIC-143/CL-3/4, ZOO-139, ZOO-135-3/4, ZOO-135/NS-3/4, ZOO-125-3/4, ZOO-142/PR-3/4, ZOO-143-3/4
Cartridge Measurements:
| Total Length (including bottom seal) | 57.8mm |
|---|---|
| Spindle Length (from top of nut) | Diameter at Widest Point: 28.7mm |
| Top Spline Diameter | 7.6mm |
| Top Spline Teeth / Notches | 20 |
| Lower Fitting Thread Diameter | 26mm |
| Barrel Diameter Below Lower Thread | 23.6m |
| Bottom Seal Colour | Blue |
| Close Direction | Clockwise Close (Anti-Clockwise Open) |
| Turn | Quarter Turn (1/4 Turn) 90° |
| Upper Thread (closer to spline) | 23.7mm |
