Matki P0000000003 Flow Cartridge for EX5 Elixir Valves (P000000003)
SUMMARY
Matki P0000000003 Flow Cartridge for EX5 Elixir Valves (P000000003)
Matki P0000000003 is a quarter-turn flow cartridge for Matki EX5 Elixir shower valves. The code variant P000000003 is also shown for this cartridge.
This cartridge controls the on-off water flow through the valve. It is anti-clockwise turn on and clockwise close, with a 20-spline spindle for the control handle. A worn flow cartridge can cause stiff operation, poor shut-off or water dripping from the shower head after the shower is turned off.
Technical Details
- - Part Number: P0000000003
- - Code variant shown: P000000003
- - Turn orientation: Anti-clockwise turn ON - clockwise close
- - Turn: Quarter turn
- - Total length: 54mm
- - Diameter at widest point: 23.8mm
- - Diameter of bottom thread: 20.6mm
- - Diameter of top spline: 7.6mm
- - Number of splines: 20
- - Diameter of top thread: 23.8mm
Confirmed Compatible Models
- - Matki EX5 (OMBG) Elixir Thermostatic Shower Valve Jan 03-Jan 06
Important Before Ordering Check
Matki EX5 Elixir valves were produced in more than one generation. Check the valve version, handle spline count, turn direction and cartridge dimensions before ordering. Do not use this part for later EX5 generations unless the existing cartridge and valve spares diagram match P0000000003.
Related Spares You May Need
- - TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved
- - Matki CS P100000159 Thermostatic Cartridge (P0000000159)
