Grohe 07150000 Headpart Flow Cartridge for Concealed Valves
Send a photo of your item and we'll help confirm it.
Summary
GROHE 07150000 3/4 Inch Long-Spindle Headpart Flow Cartridge for Concealed Valves
The GROHE 07150000 is a 3/4 inch long-spindle headpart flow cartridge used in specific GROHE concealed valves. It operates the water flow through the valve and is identified by GROHE as an old-type headpart with anti-clockwise opening operation.
A worn or damaged flow headpart can cause poor flow control, difficulty shutting the valve fully, or water continuing to drip from the shower outlet when the valve is turned off. Replacing the correct headpart can restore normal opening, closing and flow-control operation without replacing the complete concealed valve.
Technical Details
| Exact part code | 07150000 |
|---|---|
| Part type | long-spindle headpart flow cartridge |
| Application | 3/4 inch concealed valves |
| Type | old-type headpart |
| Opening direction | anti-clockwise / left-turn opening |
| Splines | 20 |
| Total length | 96.9mm |
| Spindle length | 54.2mm |
| Spline diameter | 10.9mm |
| Nut height | 8.1mm |
| Nut diameter | 16.9mm |
| Widest point diameter | 32.9mm |
| Top fitting height | 4.4mm |
| Top fitting diameter | 27.8mm |
| Shoulder thickness | 4.2mm |
| Bottom diameter | 23.8mm |
| Height from top fitting to end of splines | 62.8mm |
| Height from under shoulder to bottom | 22.1mm |
| Installation spanner size | 22mm |
| Manufacturer tightening torque | 25-30 Nm |
Confirmed Valve Fitment
Important Fitment Note: 07150000 is manufacturer-confirmed for GROHE valve codes 29 238 and 29 239. However, historical versions of these valve codes can use different cartridges, so do not assume 07150000 fits every generation. Check the existing cartridge and valve configuration before ordering.
- GROHE 29 238 3/4 Inch Valve
- GROHE 29 239 3/4 Inch Valve
Before You Order
Check the existing valve and removed headpart carefully before ordering. Confirm that the valve requires the 3/4 inch long-spindle 07150000 configuration, with 20 splines and anti-clockwise opening operation. Do not select a GROHE headpart from nominal valve size alone, as other 3/4 inch GROHE spare parts use different spindle lengths and operating mechanisms.
Installation Note
When fitting the cartridge, the sealing surfaces should be clean and the relevant O-ring and bottom seal can be lightly lubricated with suitable silicone grease. GROHE specifies a tightening torque of 25-30 Nm for this 3/4 inch headpart.
