Crosswater R1524 1/​2" Ceramic Disc Flow Cartridge (On/​Off Valve) - Hot Side Compatible Cartridge - CR-R1524

SUMMARY

Crosswater R1524 1/2 Inch Ceramic Disc Flow Cartridge (On/Off Valve) - Hot Side Compatible Cartridge - CR-R1524

The CR-R1524 is a compatible replacement for the Crosswater R1524 1/2 inch hot-side ceramic disc flow cartridge. It is used in the hot-water control of the selected Crosswater basin and bidet mixer taps listed below.

The cartridge controls water flow and shut-off as the tap handle is turned. A worn or contaminated flow cartridge can allow water to continue dripping from the spout when the tap is turned off. Trapped debris can also prevent the ceramic discs from sealing correctly, so the cartridge and valve seating should be checked when investigating a persistent drip.

Technical Details

- - Crosswater cartridge reference: R1524

- - Part Number: CR-R1524

- - Part type: ceramic disc flow cartridge / on-off valve

- - Nominal size: 1/2 inch

- - Position: hot side

- - Fitting: threaded body with a splined operating stem

Confirmed Compatible Models

- - Crosswater AL110DNC Alvero Basin Mixer

- - Crosswater AL130WNC Alvero Wall Mounted Basin 3 Hole Mixer

- - Crosswater AL135DNC Alvero Deck Mounted Basin 3 Hole Set without Waste

- - Crosswater AL210DNC Alvero Bidet Mixer Tap

- - Crosswater TO110DPC Totti Basin Monobloc Tap with Pop-Up Waste

- - Crosswater TO130WNC Totti Wall Mounted Basin 3 Hole Set

- - Crosswater TO135DPC Totti Deck Mounted Basin 3 Hole Set with Pop-Up Waste

- - Crosswater TO130WNC+ Totti II Wall Mounted Basin 3 Hole Set

Before Ordering

Check the exact tap model and confirm that you need the hot-side cartridge. Compare the existing cartridge with the product photograph, including the threaded body, operating stem and seal arrangement. The nominal 1/2 inch size alone does not confirm fitment.

Fitting and Servicing

Isolate the water supply before removing the handle, valve cover or cartridge. Use a correctly sized spanner to remove the valve and clear any trapped debris before fitting the replacement. Apply a light coating of silicone grease to the seals, reassemble the tap and check for leaks and correct shut-off.

Related Spares You May Need

- - Crosswater R1503 1/2 Inch Cold-Side Ceramic Disc Flow Cartridge - CR-R1503

- - TACSIL 3g Silicone Grease - TAC86 for lubricating cartridge seals during fitting and servicing

- - Crosswater R0318C Chrome Basin Pop-Up Waste Assembly for the TO110DPC Totti Basin Monobloc

If you are unsure which cartridge you need, use the Di Vapor part identification service.
