Crosswater R1523 3/​4" Ceramic Disc Flow Cartridge (On/​Off Valve) - Cold Side Compatible Cartridge

SUMMARY

Crosswater R1523 3/4 Inch Ceramic Disc Flow Cartridge (On/Off Valve) - Cold Side - Compatible Cartridge

This compatible ceramic disc on/off flow cartridge is for Crosswater R1523 applications in the bath fillers and bath shower mixers listed below.

The cartridge controls water flow beneath the tap handle, with ceramic discs opening and closing the water passage. Worn or contaminated discs can allow water to pass when the control is turned off, causing persistent dripping from the bath spout or shower outlet.

Technical Details

- - Crosswater part reference: R1523

- - Nominal size: 3/4 inch

- - Cartridge mechanism: ceramic disc

- - Function: on/off water flow control

- - Fitting: screw-in cartridge with a splined spindle

- - Application: bath fillers and bath shower mixers

Confirmed Compatible Models

Voyager

- - Crosswater Voyager VO322DC bath filler

- - Crosswater Voyager VO422DC bath shower mixer with kit

Logic

- - Crosswater Logic LO322DC bath filler

- - Crosswater Logic LO422DC bath shower mixer with kit

Alvero

- - Crosswater Alvero AL330DC three-hole bath mixer tap

- - Crosswater Alvero AL331WC wall-mounted three-hole bath set

Ninety

- - Crosswater Ninety BR322DC deck-mounted bath filler

- - Crosswater Ninety BR422DC bath shower mixer with kit

Zeya

- - Crosswater Zeya ZE322DC deck-mounted bath filler

- - Crosswater Zeya ZE422DC bath shower mixer with kit

Related Spares You May Need

- - Crosswater R1511 quarter-turn bath cartridge - A separate cartridge for the Voyager, Logic, Ninety and Zeya models listed above and Alvero AL331WC

- - TACSIL 3g WRAS-approved silicone grease - For lubricating cartridge O-rings and seals during fitting

- - GROHE 18007031 SYNTHESO LM 220 silicone grease 2g - An alternative lubricant for cartridge O-rings and seals

Before Ordering

Check your exact tap model, the dimensions of your existing cartridge and the direction required to open and close the water flow. Compare the cartridge body, threads, sealing arrangement and splined spindle with the product photographs. These details should be checked together when selecting the correct part.

Fitting and Maintenance

Isolate the hot and cold water supplies before removing the cartridge, and check the valve housing for debris before fitting. Apply a thin coating of suitable silicone grease to the O-rings to help prevent them from twisting or pinching during installation. Persistent dripping can also result from debris or incorrect seating, so inspect these areas when servicing the tap.

If you are unsure which part you need, use our part identification service for help.
