Crosswater Crossbox 1 Outlet Cartridge (E250004.00000SC)

SUMMARY

Crosswater Crossbox 1 Outlet Cartridge (E250004.00000SC)

The Crosswater E250004.00000SC is a 1 outlet flow cartridge for selected Crossbox 1000 concealed thermostatic shower valves. It operates the shower water flow through the single outlet, allowing the user to turn the shower on and off independently of the temperature setting.

This is the outlet flow cartridge, not the thermostatic temperature-control cartridge. A faulty flow cartridge can cause a shower head to continue dripping after the valve is switched off or make the on/off control difficult to operate. Check the existing cartridge and valve model before ordering, as Crossbox two-outlet and three-outlet arrangements use different outlet cartridges.

Technical Details

- - Part Number: E250004.00000SC

- - Part type: 1 outlet shower flow / on-off cartridge

- - Application: Crossbox non-push concealed thermostatic shower valves with one outlet

- - Valve arrangement: Crossbox universal rough-in body fitted with a 1 outlet finishing kit

- - Function: water flow and shut-off control, separate from temperature adjustment

- - Separate temperature cartridge: E250011.00000SC

- - Other Crossbox outlet variants: E250005.000HESC for 2 outlets and E250006.00000SC for 3 outlets

Confirmed Compatible Models

Atoll

- - Crosswater ATCB1000LBPM Atoll Crossbox 1 Outlet Trim & Valves

Belgravia

- - Crosswater BLCB1000LBPC Belgravia Crossbox 1000 Finishing Kit

Marvel

- - Crosswater MVCB1000LBPC Marvel 1000 Crossbox Chrome

- - Crosswater MVCB1000LBPM Marvel 1000 Crossbox Matt Black

MPRO

- - Crosswater PROCB1000LBPC MPRO Crossbox 1 Outlet Chrome

- - Crosswater PROCB1000LBPM MPRO Crossbox 1 Outlet Matt Black

- - Crosswater PROCB1000LBPF MPRO 1000 Crossbox Brushed Brass

- - Crosswater PROCB1000LBPW MPRO Crossbox 1 Outlet Matt White

MPRO Industrial

- - Crosswater PRICB1000LBPM MPRO Industrial Crossbox 1000 Matt Black

Installation and Ordering Advice

Isolate the water supply before removing the existing cartridge. Compare its code, shape and fitting arrangement with E250004.00000SC, then apply suitable silicone grease sparingly to the O-rings and sealing surfaces during installation. The Crossbox universal rough-in body can serve different outlet arrangements, so identify the fitted finishing kit rather than relying on the valve body alone.

If you are unsure which cartridge you need, use the Di Vapor part identification service.

Related Spares You May Need

- - TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved

- - Crosswater Crossbox Thermostatic Cartridge E250011.00000SC

- - Crosswater Crossbox Temperature Override Ring A059041.01500ZZ

- - Crosswater Crossbox Spare Fitting Kit E003090.00000SA

- - Crosswater Crossbox Screw Kit E250008.00000SA

- - Crosswater Marvel/Atoll Crossbox Handles Pair Chrome E005033.521HESC

- - Crosswater Marvel/Atoll Crossbox Backplate Chrome E250025.521HESC

- - Crosswater Marvel/Atoll Crossbox Handle Stainless E005033.575ZESC
