Bristan CART-04945 Diverter Cartridge for Prism and Trinity Valves
SUMMARY
Bristan CART-04945 Diverter Cartridge for Prism and Trinity Shower Valves
The Bristan CART-04945 is a diverter cartridge used inside selected older Bristan Prism and Trinity shower diverter assemblies. It operates the outlet selection mechanism, directing the water supply between the available shower outlets.
A worn or damaged diverter cartridge can make it difficult to select an outlet correctly or can allow water to pass to an unintended outlet. Bristan has used different diverter cartridges across later product revisions, so the existing cartridge, model and measurements should be checked carefully before ordering.
Technical Details
- - Part number: CART-04945
- - Cartridge type: diverter / outlet selector cartridge
- - Close Direction: Anti-Clockwise Close (Clockwise Open)
- - Total length: 64mm fully compressed including the bottom seal and excluding the protruding rivet
- - Widest diameter: 29.4mm
- - Barrel diameter: 22.5mm
- - Top spline diameter: 7.5mm
- - Top spline: 20 teeth / notches
Confirmed Applications
- - Bristan PM SDIV C GEN1 Prism Contemporary In Line Divertor - Two Outlets
- - Bristan Trinity Traditional In Line Divertor - 2 Outlets - BR DV 288
- - Bristan TY CSHXDIV C Trinity Thermostatic Dual Control Shower Valve
- - Bristan TY CSHXDIV C W Trinity shower valve
- - Bristan TY SHXDIV C W Trinity shower valve
Before Ordering
Later revisions of Bristan Prism and Trinity diverters can use different cartridges, so do not rely on the model family alone. Compare the existing cartridge and measurements with CART-04945 before ordering.
If you are unsure whether this is the correct cartridge, use the Di Vapor Part Identification Service for help.
Related Spares You May Need
- - Bristan OR 08015 O Ring 17.17mm x 1.78mm
- - Bristan NUT 04335CSET-BL Compression Nut & Olive
