Bathstore 127mm 3/4" Quarter Turn Flow Cartridge - 88mm Spindle
Part number: JH90945
Price: £59.95
Sale: £18.80
You save: £41.15 (69%)
Price includes UK VAT (Region: UK▼)
In stock
Is this the right part?
Send a photo of your item and we'll help confirm it.
Product description
Summary
Bathstore 127mm 3/4" Quarter Turn Flow Cartridge - 88mm Spindle - Anti-Clockwise Open. This cartridge is often used in deck mounted valves. O-rings can be used on the two grooves on the spindle which stops water flowing down under the bath.
Please note that the seal colour is now red however this doesn't affect the cartridge in any way.
Cartridge Measurements:
| Total Length (including bottom seal) | 126.8mm |
|---|---|
| Spindle Length | 87.7mm |
| Diameter at Widest Point | 28.8mm |
| Top Spline Diameter | 7.6mm |
| Top Spline Teeth / Notches | 20 |
| Barrel Diameter | 23.6mm |
| Lower Thread | 3/4" BSP |
| Upper Thread (closer to spline) | 24mm |
